| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 844150098 | CONTROL VALVE, ASSY. (SERIES TYPE) | 1 | SN: 8901442- |
|||
| ? | 844160123 | • BLOCK, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160129 | • • VALVE, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160023 | • • • O-RING | 1 | SN: 8901442- |
|||
| ? | 844160131 | • • PROTECTION, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160137 | • • KIT, GASKET | 1 | SN: 8901442- |
|||
| ? | 844160128 | • • SPOOL RETURN UNIT | 1 | SN: 8901442- |
|||
| ? | 844160117 | • • SPRING | 1 | SN: 8901442- |
|||
| ? | 844160013 | • • VALVE, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160133 | • • • KIT, GASKET | 1 | SN: 8901442- |
|||
| ? | 844160012 | • • SAFETY VALVE, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160133 | • • • KIT, GASKET | 1 | SN: 8901442- |
|||
| ? | 844160125 | • BLOCK, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160129 | • • VALVE, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160023 | • • • O-RING | 1 | SN: 8901442- |
|||
| ? | 844160131 | • • PROTECTION, ASSY. | 1 | SN: 8901442- |
|||
| ? | 844160130 | • • KIT, GASKET | 1 | SN: 8901442- |
|||
| ? | 844160128 | • • SPOOL RETURN UNIT | 1 | SN: 8901442- |
|||
| ? | 844160117 | • • • SPRING | 1 | SN: 8901442- |
|||
| ? | 844160012 | • • SAFETY VALVE, ASSY. | 2 | SN: 8901442- |
|||
| ? | 844160133 | • • • KIT, GASKET | 1 | SN: 8901442- |
|||
| ? | SEE FIG. 6250 | 6250 |
