| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 395-02-11242 | SLEEVE | 1 | SN: 395F70241-395F70334 |
A | ||
| ? | 395-02-11243 | SLEEVE | 1 | SN: 395F70335- |
B | ||
| ? | 07281-01159 | CLAMP | 4 | SN: 395F70241- |
|||
| ? | 21D-09-81940 | CLAMP | 1 | SN: 395F70241- |
|||
| ? | 395-02-11220 | SLEEVE | 1 | SN: 395F70241- |
|||
| ? | 395-02-11421 | PIPE | 1 | SN: 395F70241-395F70404 |
A | ||
| ? | 395-02-11422 | PIPE | 1 | SN: 395F70405- |
B | ||
| ? | 01016-50825 | BOLT | 1 | SN: 395F70241- |
|||
| ? | 01643-10823 | WASHER | 5 | SN: 395F70241- |
|||
| ? | 01010-80820 | BOLT | 1 | SN: 395F70241- |
|||
| ? | 395-02-11370 | HOSE | 1 | SN: 395F70241-395F70334 |
A | ||
| ? | 395-02-11371 | HOSE | 1 | SN: 395F70335-395F70393 |
B | ||
| ? | 395-02-11520 | HOSE | 1 | SN: 395F70394- |
C | ||
| ? | 07281-00259 | CLAMP | 2 | SN: 395F70241- |
|||
| ? | 42N-54-12780 | PRE-FUEL FILTER | 1 | SN: 395F70241- |
|||
| ? | 395-54-11680 | FLANGE | 1 | SN: 395F70241- |
|||
| ? | 395-54-11690 | FLANGE | 1 | SN: 395F70241- |
|||
| ? | 42N-54-12760 | GASKET | 1 | SN: 395F70241- |
|||
| ? | 21D-09-24180 | NUT | 3 | SN: 395F70241- |
|||
| ? | 395-02-11400 | SLEEVE | 1 | SN: 395F70241- |
|||
| ? | 395-02-11391 | HOSE | 1 | SN: 395F70241- |
|||
| ? | 07281-01279 | CLAMP | 3 | SN: 395F70241- |
|||
| ? | 395-02-11491 | SUPPORT | 1 | SN: 395F70241- |
|||
| ? | 01016-51040 | BOLT | 2 | SN: 395F70241- |
|||
| ? | 395-03-11350 | PLUG | 1 | SN: 395F70241- |
|||
| ? | 01643-11032 | WASHER | 2 | SN: 395F70241- |
|||
| ? | 21D-09-24190 | NUT | 2 | SN: 395F70241- |
|||
| ? | SEE FIG. 0155 | 0155 | |||||
| ? | SEE FIG. 4620 | 4620 |
