| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 395-54-11010 | HOOD, ENGINE | 1 | SN: 395F70241-395F70404 |
|||
| ? | 395-54-11390 | GASKET | 1 | SN: 395F70241-395F70404 |
|||
| ? | 395-54-11L92 | GASKET | 1 | SN: 395F70241-395F70404 |
|||
| ? | 395-47-11560 | HINGE | 2 | SN: 395F70241-395F70404 |
|||
| ? | 01010-80820 | BOLT | 4 | SN: 395F70241-395F70404 |
|||
| ? | 01643-10823 | SPRING WASHER | 8 | SN: 395F70241-395F70404 |
|||
| ? | 20M-54-R2250 | BOOT | 1 | SN: 395F70241-395F70404 |
|||
| ? | 22E-54-11650 | PUSH-BUTTON, ASSY. | 1 | SN: 395F70241-395F70404 |
|||
| ? | 01010-80655 | BOLT | 1 | SN: 395F70241-395F70404 |
|||
| ? | 21D-09-21140 | NUT | 1 | SN: 395F70241-395F70404 |
|||
| ? | 395-54-11M40 | BRACKET | 1 | SN: 395F70241-395F70404 |
|||
| ? | 37A-09-1T017 | SCREW | 2 | SN: 395F70241-395F70404 |
|||
| ? | 37A-54-11290 | LOCK, ASSY. | 1 | SN: 395F70241-395F70404 |
|||
| ? | 01225-40835 | SCREW WASHER | 2 | SN: 395F70241-395F70404 |
|||
| ? | 01010-80840 | BOLT | 1 | SN: 395F70241-395F70404 |
|||
| ? | 21D-09-24180 | NUT, STOP | 1 | SN: 395F70241-395F70404 |
|||
| ? | 01010-81025 | BOLT | 4 | SN: 395F70241-395F70404 |
|||
| ? | 01643-11032 | WASHER | 4 | SN: 395F70241-395F70404 |
|||
| ? | SEE FIG. 4620 | 4620 |
