| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 395-70-11119 | ARM | 1 | SN: 395F71003- |
|||
| ? | 395-70-11D43 | • CLAMP | 1 | SN: 395F71003- |
|||
| ? | 01016-51040 | BOLT | 2 | SN: 395F71003- |
|||
| ? | 01643-11032 | WASHER | 14 | SN: 395F71003- |
|||
| ? | 395-70-12110 | BUSHING | 2 | SN: 395F71003- |
|||
| ? | 21D-09-89140 | GREASE NIPPLE | 3 | SN: 395F71003- |
|||
| ? | 01643-11232 | WASHER | 3 | SN: 395F71003- |
|||
| ? | 395-70-12122 | SLIDE BLOCK | 2 | SN: 395F71003- |
|||
| ? | 395-70-12870 | SHIM, 1.000 mm | 8 | SN: 395F71003- |
|||
| ? | 395-70-12880 | SHIM, 0.500 mm | 2 | SN: 395F71003- |
|||
| ? | 01016-51030 | BOLT | 12 | SN: 395F71003- |
|||
| ? | 395-70-12134 | SLIDE BLOCK | 2 | SN: 395F71003- |
|||
| ? | 395-70-14150 | SUPPORT, R.H. | 1 | SN: 395F71003- |
|||
| ? | 395-70-14181 | SCRAPER | 4 | SN: 395F71003- |
|||
| ? | 395-70-14190 | PLATE | 4 | SN: 395F71003- |
|||
| ? | 21D-09-15720 | SCREW | 8 | SN: 395F71003- |
|||
| ? | 01601-20411 | SPRING WASHER | 8 | SN: 395F71003- |
|||
| ? | 01016-50825 | BOLT | 4 | SN: 395F71003- |
|||
| ? | 01643-10823 | WASHER | 52 | SN: 395F71003- |
|||
| ? | 395-70-14140 | SUPPORT, L.H. | 1 | SN: 395F71003- |
|||
| ? | 395-70-12852 | PLATE | 4 | SN: 395F71003- |
|||
| ? | 395-70-12571 | SLIDE BLOCK | 4 | SN: 395F71003- |
|||
| ? | 395-70-12451 | SHIM, 1.000 mm | 4 | SN: 395F71003- |
|||
| ? | 395-70-12460 | SHIM, 0.500 mm | 8 | SN: 395F71003- |
|||
| ? | 01010-80820 | BOLT | 24 | SN: 395F71003- |
|||
| ? | 395-70-12842 | CONTROL VALVE | 1 | SN: 395F71003- |
|||
| ? | 01010-81250 | BOLT | 3 | SN: 395F71003- |
|||
| ? | 21D-09-89140 | GREASE NIPPLE | 2 | SN: 395F71003- |
