| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 312608083 | PEDAL LEVER | 1 | SN: 395F71003- |
|||
| ? | 801104081 | SCREW | 1 | SN: 395F71003- |
|||
| ? | 01598-00608 | NUT | 1 | SN: 395F71003- |
|||
| ? | 42N-54-15620 | PEDAL | 1 | SN: 395F71003- |
|||
| ? | 42N-56-12880 | WASHER | 2 | SN: 395F71003- |
|||
| ? | 04064-01410 | RING, SNAP | 1 | SN: 395F71003- |
|||
| ? | 395-56-13980 | PIN | 1 | SN: 395F71003- |
|||
| ? | 395-56-11H60 | RING | 1 | SN: 395F71003- |
|||
| ? | 395-56-11H50 | BEARING | 1 | SN: 395F71003- |
|||
| ? | 42N-54-17390 | STOPPER | 1 | SN: 395F71003- |
|||
| ? | 21D-09-21720 | NUT | 2 | SN: 395F71003- |
|||
| ? | 37A-09-61019 | PIN | 1 | SN: 395F71003- |
|||
| ? | 37B-09-2C006 | SPRING | 1 | SN: 395F71003- |
|||
| ? | 395-56-14380 | CABLE | 1 | SN: 395F71003- |
|||
| ? | 21D-09-15170 | SCREW | 1 | SN: 395F71003- |
|||
| ? | 01643-11445 | WASHER | 1 | SN: 395F71003- |
|||
| ? | 01598-00809 | NUT, STOP | 1 | SN: 395F71003- |
|||
| ? | 21D-09-21720 | NUT | 1 | SN: 395F71003- |
|||
| ? | 01643-10823 | WASHER | 1 | SN: 395F71003- |
|||
| ? | 395-01-11212 | SUPPORT | 1 | SN: 395F71003- |
|||
| ? | 01010-80620 | BOLT | 2 | SN: 395F71003- |
|||
| ? | 01640-20610 | WASHER | 2 | SN: 395F71003- |
|||
| ? | 01580-10605 | NUT | 6 | SN: 395F71003- |
|||
| ? | 395-01-11280 | SLEEVE | 1 | SN: 395F71003- |
|||
| ? | 37A-09-1J074 | SCREW | 1 | SN: 395F71003- |
|||
| ? | 04434-51210 | CLAMP | 1 | SN: 395F71003- |
|||
| ? | 01010-80816 | BOLT | 1 | SN: 395F71003- |
|||
| ? | 01643-10823 | WASHER | 1 | SN: 395F71003- |
