| Наименование | Страница | Код страницы |
|---|---|---|
| 10-SPOOL CONTROL VALVE (WITH BACKHOE PPC) (1/16) | F-6260 | 6260 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-1A-15605) | CONTROL VALVE, ASSEMBLY | 1 | SN: F20003- |
6260 | ||
| ? | 723-11-29830 | • RETAINER | 2 | SN: F20003- |
|||
| ? | 723-11-29840 | • SPRING | 2 | SN: F20003- |
|||
| ? | 723-11-37251 | • CASE, SPRING | 1 | SN: F20003- |
|||
| ? | 723-11-37540 | • CASE, SPRING | 1 | SN: F20003- |
|||
| ? | 706-47-60230 | • BOLT | 2 | SN: F20003- |
|||
| ? | 702-16-55270 | • BOLT | 1 | SN: F20003- |
|||
| ? | 01252-60650 | • BOLT | 2 | SN: F20003- |
|||
| ? | 01252-60640 | • BOLT | 1 | SN: F20003- |
|||
| ? | 723-11-37450 | • RETAINER | 4 | SN: F20003- |
|||
| ? | 723-11-38130 | • SPRING | 4 | SN: F20003- |
|||
| ? | 01252-60640 | • BOLT | 4 | SN: F20003- |
|||
| ? | 723-11-17341 | • SPRING | 2 | SN: F20003- |
|||
| ? | 723-11-17361 | • BOLT | 2 | SN: F20003- |
|||
| ? | 723-11-27220 | • PLUG | 1 | SN: F20003- |
|||
| ? | 01252-60620 | • BOLT | 4 | SN: F20003- |
|||
| ? | 01252-60612 | • BOLT | 1 | SN: F20003- |
|||
| ? | 723-11-27421 | • CASE, SPRING | 1 | SN: F20003- |
|||
| ? | 702-21-54260 | • O-RING | 2 | SN: F20003- |
|||
| ? | 07002-10823 | • O-RING | 1 | SN: F20003- |
|||
| ? | 709-32-11760 | • O-RING | 2 | SN: F20003- |
