| Наименование | Страница | Код страницы |
|---|---|---|
| OPERATOR'S SEAT (KAB SEATING MODEL 855) (2/2) | E-5720 | 5720 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 42N-54-14590 | SEAT, SUPPORT ASSEMBLY | 1 | SN: F20459- |
|||
| ? | 42N-54-15910 | BOLT | 4 | SN: F20459- |
|||
| ? | 01643-11032 | WASHER | 4 | SN: F20459- |
|||
| ? | 42N-56-15010 | SWITCH, ASSEMBLY | 1 | SN: F20459- |
|||
| ? | 42N-06-12391 | • SWITCH | 1 | SN: F20459- |
|||
| ? | 42N-06-12470 | • SWITCH | 1 | SN: F20459- |
|||
| ? | 01252-70420 | • BOLT | 4 | SN: F20459- |
|||
| ? | 42N-06-12380 | • WIRING HARNESS, SEAT SUPPORT | 1 | SN: F20459- |
|||
| ? | 42N-54-15910 | BOLT | 4 | SN: F20459- |
|||
| ? | 01643-11032 | WASHER | 4 | SN: F20459- |
|||
| ? | (42N-56-13850) | OPERATOR'S SEAT | 1 | SN: F20459- |
5720 | ||
| ? | 42N-54-15950 | SCREW | 4 | SN: F20459- |
|||
| ? | 01643-10823 | WASHER | 4 | SN: F20459- |
|||
| ? | 395-56-13600 | NUT | 4 | SN: F20459- |
|||
| ? | 42N-54-14321 | PROTECTION | 1 | SN: F20459- |
|||
| ? | 395-56-12B20 | BRACKET | 2 | SN: F20459- |
|||
| ? | 42N-54-15160 | BOLT | 1 | SN: F20459- |
|||
| ? | 01640-30610 | WASHER | 1 | SN: F20459- |
|||
| ? | 42N-06-12330 | WIRING HARNESS, OPERATOR'S SEAT | 1 | SN: F20459- |
|||
| ? | 21D-06-11830 | • FUSE 15A | 1 | SN: F20459- |
|||
| ? | 21D-54-14791 | GROMMET | 1 | SN: F20459- |
