| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | YMR000599 | ROTOR, ASSY. | 1 | SN: 3440007- |
|||
| ? | YMR000295 | • SEAL, OIL | 1 | SN: 3440007- |
|||
| ? | YMR000283 | FLANGE, GEAR HOUSING | 1 | SN: 3440007- |
|||
| ? | YMR000066 | STUD | 3 | SN: 3440007- |
|||
| ? | YMR000078 | CAP, LUB. OIL SUPPLY | 1 | SN: 3440007- |
|||
| ? | YMR000083 | COVER | 1 | SN: 3440007- |
|||
| ? | YMR000457 | GASKET | 1 | SN: 3440007- |
|||
| ? | YMR000296 | PIPE | 2 | SN: 3440007- |
|||
| ? | YMR000073 | O-RING | 1 | SN: 3440007- |
|||
| ? | YMR000383 | O-RING | 2 | SN: 3440007- |
|||
| ? | YMR000384 | O-RING | 1 | SN: 3440007- |
|||
| ? | YMR000400 | BOLT PLATED | 4 | SN: 3440007- |
|||
| ? | YMR000402 | BOLT | 1 | SN: 3440007- |
|||
| ? | YMR000407 | BOLT | 6 | SN: 3440007- |
|||
| ? | YMR000409 | BOLT | 3 | SN: 3440007- |
|||
| ? | YMR000412 | SCREW | 4 | SN: 3440007- |
|||
| ? | YMR000402 | BOLT | 3 | SN: 3440007- |
|||
| ? | YMR000403 | BOLT PLATED | 2 | SN: 3440007- |
|||
| ? | YMR000425 | NUT | 3 | SN: 3440007- |
|||
| ? | YMR000439 | GASKET | 4 | SN: 3440007- |
|||
| ? | YMR000439 | GASKET | 1 | SN: 3440007- |
|||
| ? | YMR000053 | COVER | 1 | SN: 3440007- |
|||
| ? | YMR000388 | O-RING | 1 | SN: 3440007- |
|||
| ? | YMR000395 | SCREW | 2 | SN: 3440007- |
