| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37B-01-11101) | ENGINE, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM719810-01500 | • HOUSING ASSY., GEAR | 1 | ENSN: 17583- |
|||
| ? | YM129795-01800 | • • SEAL, OIL | 1 | ENSN: 17583- |
|||
| ? | YM129400-01520 | • FLANGE, GEAR HOUSING | 1 | ENSN: 17583- |
|||
| ? | YM121450-01560 | • STUD | 3 | ENSN: 17583- |
|||
| ? | YM124160-01751 | • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM24311-000320 | • O-RING | 1 | ENSN: 17583- |
|||
| ? | YM119225-11740 | • UNION | 1 | ENSN: 17583- |
|||
| ? | YM129795-01950 | • PIPE | 2 | ENSN: 17583- |
|||
| ? | YM129150-03100 | • RETAINER | 1 | ENSN: 17583- |
|||
| ? | YM121850-51960 | • O-RING | 1 | ENSN: 17583- |
|||
| ? | YM24311-000160 | • O-RING | 2 | ENSN: 17583- |
|||
| ? | YM124240-01871 | • COVER | 1 | ENSN: 17583- |
|||
| ? | YM26106-080122 | • BOLT PLATED | 4 | ENSN: 17583- |
|||
| ? | YM26106-080162 | • BOLT | 1 | ENSN: 17583- |
|||
| ? | YM26106-080162 | • BOLT | 3 | ENSN: 17583- |
|||
| ? | YM26106-080202 | • BOLT | 2 | ENSN: 17583- |
|||
| ? | YM26106-080452 | • BOLT | 6 | ENSN: 17583- |
|||
| ? | YM26106-080552 | • BOLT | 3 | ENSN: 17583- |
|||
| ? | YM129001-91841 | • SCREW | 4 | ENSN: 17583- |
|||
| ? | YM26306-080002 | • NUT | 3 | ENSN: 17583- |
|||
| ? | YM22190-080002 | • GASKET | 4 | ENSN: 17583- |
|||
| ? | YM22190-080002 | • GASKET | 1 | ENSN: 17583- |
|||
| ? | YM121023-01550 | • COVER | 1 | ENSN: 17583- |
|||
| ? | YM24341-000240 | • O-RING | 1 | ENSN: 17583- |
|||
| ? | YM26106-060162 | • BOLT | 2 | ENSN: 17583- |
|||
| ? | YM977770-01212 | • GASKET, LIQUID | 1 | ENSN: 17583- |
|||
| ? | YM171031-11741 | • PIPE | 1 | ENSN: 17583- |
|||
| ? | YM119225-11750 | • NUT | 1 | ENSN: 17583- |
|||
| ? | YM24311-000300 | • O-RING | 1 | ENSN: 17583- |
|||
| ? | YM24311-000320 | • O-RING | 1 | ENSN: 17583- |
