| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37B-01-11101) | ENGINE, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM729407-01561 | • CYLINDER BLOCK, ASSY. | 1 | ENSN: 17583- |
|||
| ? | ☆ | • • CYLINDER BLOCK, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129795-02411 | • • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YM124160-01910 | • • • PLUG | 2 | ENSN: 17583- |
|||
| ? | YM124160-01910 | • • • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM171051-01921 | • • • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM129150-02020 | • • • SCREW | 10 | ENSN: 17583- |
|||
| ? | YM23876-010000 | • • • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM129001-01250 | • • • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM27241-120000 | • • • PLUG | 2 | ENSN: 17583- |
|||
| ? | YM27241-300000 | • • • PLUG | 8 | ENSN: 17583- |
|||
| ? | YM23876-030000 | • • • PLUG | 1 | ENSN: 17583- |
|||
| ? | YM129001-02930 | • • BEARING | 5 | ENSN: 17583- |
A | ||
| ? | YM129150-02870 | • • BEARING (--0.25 mm) | 5 | ENSN: 17583- |
B | ||
| ? | YM129150-02930 | • • BEARING, THRUST | 2 | ENSN: 17583- |
A | ||
| ? | YM129150-02940 | • • BEARING, THRUST (+0.25 mm) | 2 | ENSN: 17583- |
B | ||
| ? | YM129150-01200 | • STUD | 18 | ENSN: 17583- |
|||
| ? | YM129407-01340 | • GASKET | 1 | ENSN: 17583- |
