| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37B-01-11101) | ENGINE, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129400-77012 | • STARTER MOTOR | 1 | ENSN: 17583- |
|||
| ? | YM129486-77400 | • • ROTOR | 1 | ENSN: 17583- |
|||
| ? | YM171008-77410 | • • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YM171008-77420 | • • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YM129400-77441 | • • COIL ASSY.,FIELD | 1 | ENSN: 17583- |
|||
| ? | YM129486-77460 | • • • BRUSH, ASSY. | 2 | ENSN: 17583- |
|||
| ? | YM129486-77470 | • • HOLDER BRUSH, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129486-77460 | • • • BRUSH, ASSY. | 2 | ENSN: 17583- |
|||
| ? | YM129486-77490 | • • • SPRING | 4 | ENSN: 17583- |
|||
| ? | YM129900-77460 | • • COVER, REAR | 1 | ENSN: 17583- |
|||
| ? | YM171008-77510 | • • HOUSING, GEAR | 1 | ENSN: 17583- |
|||
| ? | YM129400-77520 | • • HOUSING, GEAR | 1 | ENSN: 17583- |
|||
| ? | YM129400-77531 | • • SWITCH, MAGNETIC | 1 | ENSN: 17583- |
|||
| ? | YM171008-77540 | • • LEVER SET, SHIFT | 1 | ENSN: 17583- |
|||
| ? | YM129400-77571 | • • COVER DUST PAN, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129900-77640 | • • BOLT | 2 | ENSN: 17583- |
|||
| ? | YM171008-77650 | • • PINION, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM171008-77660 | • • • SHAFT | 1 | ENSN: 17583- |
|||
| ? | YM171008-77670 | • • • KIT, STOP SET, PINION | 1 | ENSN: 17583- |
|||
| ? | YMX2114555500 | • • • CLUTCH, STARTER | 1 | ENSN: 17583- |
|||
| ? | YMX2114955020 | • • • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YMX2240410100 | • • • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YM26106-060322 | • • SCREW | 2 | ENSN: 17583- |
|||
| ? | YM26106-060402 | • • SCREW | 3 | ENSN: 17583- |
|||
| ? | YM26116-120252 | • BOLT PLATED | 2 | ENSN: 17583- |
|||
| ? | YM22217-080000 | • SPRING WASHER | 1 | ENSN: 17583- |
|||
| ? | YM26756-080002 | • NUT | 1 | ENSN: 17583- |
|||
| ? | SEE FIG. 0211 | 0211 |
