| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (37B-01-11101) | ENGINE, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129612-77230 | • ALTERNATOR, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129612-77700 | • • ROTOR,ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129612-77710 | • • BEARING | 1 | ENSN: 17583- |
|||
| ? | YM129612-77720 | • • COIL ASSY.,FIELD | 1 | ENSN: 17583- |
|||
| ? | YM129612-77730 | • • COVER, ASSY. | 1 | ENSN: 17583- |
|||
| ? | YM129612-77740 | • • PULLEY | 1 | ENSN: 17583- |
|||
| ? | YM129612-77750 | • • KIT, SCREW | 1 | ENSN: 17583- |
|||
| ? | YM129136-77251 | • SCREW | 1 | ENSN: 17583- |
|||
| ? | YM119820-77340 | • SPACER | 1 | ENSN: 17583- |
|||
| ? | YM129612-77260 | • NUT | 1 | ENSN: 17583- |
|||
| ? | YM129100-77320 | • ADJUSTER, BELT | 1 | ENSN: 17583- |
|||
| ? | YM119810-77340 | • BOLT | 1 | ENSN: 17583- |
|||
| ? | YM22117-050000 | • WASHER | 1 | ENSN: 17583- |
|||
| ? | YM26716-050002 | • NUT | 1 | ENSN: 17583- |
|||
| ? | YM26106-080502 | • BOLT | 1 | ENSN: 17583- |
|||
| ? | SEE FIG. 0205 | 0205 | |||||
| ? | SEE FIG. 0502 | 0502 |
