| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 37A-54-15100 | DOOR, ASSY. | 1 | SN: 37BTF00003-37BTF00133 |
A | ||
| ? | 37A-54-15101 | DOOR, ASSY. | 1 | SN: 37BTF00134- |
B | ||
| ? | 37A-54-15110 | • CAB DOOR | 1 | SN: 37BTF00003- |
|||
| ? | 37A-54-15130 | • • GLASS | 1 | SN: 37BTF00003- |
|||
| ? | 878000333 | • • KIT, SIZING | 1 | SN: 37BTF00003- |
|||
| ? | 37A-54-15120 | • • FRAME, DOOR | 1 | SN: 37BTF00003- |
|||
| ? | 37A-54-16110 | • WIPER MOTOR | 1 | SN: 37BTF00003- |
|||
| ? | 37A-06-11860 | • WIRING HARNESS | 1 | SN: 37BTF00003- |
|||
| ? | 3F0547767 | • COVER | 1 | SN: 37BTF00003- |
|||
| ? | 816215051 | • ARM, WIPER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-54-16140 | • WIPER BLADE | 1 | SN: 37BTF00003- |
|||
| ? | 885081165 | • SWITCH, WIPER | 1 | SN: 37BTF00003- |
|||
| ? | 37A-54-15250 | • HOOK | 1 | SN: 37BTF00003-37BTF00133 |
A | ||
| ? | 37A-54-15251 | • HOOK | 1 | SN: 37BTF00134- |
B | ||
| ? | 801703409 | • NUT | 2 | SN: 37BTF00003- |
|||
| ? | 37A-54-15290 | • PIN | 2 | SN: 37BTF00003- |
|||
| ? | 801703410 | • NUT | 2 | SN: 37BTF00003- |
|||
| ? | 802070012 | • WASHER | 2 | SN: 37BTF00003- |
|||
| ? | 37A-54-15510 | • BUSHING | 4 | SN: 37BTF00003- |
|||
| ? | 37A-54-15270 | • HANDLE | 1 | SN: 37BTF00003- |
|||
| ? | 801200622 | • SCREW | 2 | SN: 37BTF00003- |
|||
| ? | 37A-54-15260 | • LOCK, BLOCK | 1 | SN: 37BTF00003- |
|||
| ? | 801250062 | • SCREW | 3 | SN: 37BTF00003- |
|||
| ? | 37A-54-15991 | • HANDLE | 1 | SN: 37BTF00003- |
|||
| ? | 801015066 | • BOLT | 2 | SN: 37BTF00003- |
|||
| ? | 37A-54-15720 | • GASKET | 1 | SN: 37BTF00003- |
|||
| ? | 802070006 | • WASHER | 2 | SN: 37BTF00003- |
|||
| ? | 801250059 | • SCREW | 2 | SN: 37BTF00003- |
|||
| ? | 37A-06-11820 | WIRING HARNESS | 1 | SN: 37BTF00003- |
