| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 42N-03-11100 | RADIATOR, ASSY. | 1 | SN: F00003- |
|||
| ? | 226-03-11480 | • BOLT | 8 | SN: F00003- |
|||
| ? | 42N-03-11650 | • THRUST WASHER | 2 | SN: F00003- |
|||
| ? | 42N-03-11620 | • WASHER | 4 | SN: F00003- |
|||
| ? | 42N-03-11610 | • DAMPER | 4 | SN: F00003- |
|||
| ? | 42N-03-11590 | • THRUST WASHER | 2 | SN: F00003- |
|||
| ? | 42N-03-11640 | • STUD | 2 | SN: F00003- |
|||
| ? | 42N-03-11630 | • NUT, STOP | 2 | SN: F00003- |
|||
| ? | 42N-03-11510 | • CASE, RADIATOR, ASSY. | 1 | SN: F00003- |
|||
| ? | 226-03-11560 | • PLUG | 1 | SN: F00003- |
|||
| ? | 42N-03-11530 | • FRAME | 1 | SN: F00003- |
|||
| ? | 42N-03-11660 | • CLIP | 2 | SN: F00003- |
|||
| ? | 42N-03-11540 | • GASKET | 2 | SN: F00003- |
|||
| ? | 226-03-11490 | • WASHER | 8 | SN: F00003- |
|||
| ? | 42N-03-11580 | • NUT | 6 | SN: F00003- |
|||
| ? | 42N-03-11520 | • CONVEYOR | 1 | SN: F00003- |
