| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 42N-06-15960 | REFUELLING PUMP HARNESS, ASSY | 1 | SN: F50003- |
|||
| ? | 42N-06-13410 | • REFUELLING PUMP HARNESS | 1 | SN: F50003- |
|||
| ? | 42N-06-11380 | • WIRING HARNESS, SELF SUPPLY PUMP | 1 | SN: F50003- |
|||
| ? | 01010-80614 | BOLT | 4 | SN: F50003- |
|||
| ? | 21D-09-24160 | NUT, STOP | 4 | SN: F50003- |
|||
| ? | 42N-04-11540 | SUPPORT | 1 | SN: F50003- |
|||
| ? | 01010-81025 | BOLT | 2 | SN: F50003- |
|||
| ? | 42N-06-11660 | SUPPORT | 1 | SN: F50003- |
|||
| ? | 37A-09-1U084 | SCREW | 1 | SN: F50003- |
|||
| ? | 01643-10623 | SPRING WASHER | 1 | SN: F50003- |
|||
| ? | 21D-09-21420 | NUT | 1 | SN: F50003- |
|||
| ? | 42N-54-12570 | COVER, FRONT, L.H. | 1 | SN: F50003- |
|||
| ? | 07281-00197 | CLAMP | 4 | SN: F50003- |
|||
| ? | 42N-04-11551 | HOSE | 1 | SN: F50003- |
|||
| ? | 21D-04-11420 | HOSE | 1 | SN: F50003- |
|||
| ? | 42N-04-11510 | TANK | 1 | SN: F50003- |
|||
| ? | 42N-04-11580 | HOSE | 1 | SN: F50003- |
|||
| ? | 07281-00167 | CLAMP | 1 | SN: F50003- |
|||
| ? | 20R-06-R1101 | SEAL | 1 | SN: F50003- |
|||
| ? | 42N-04-11590 | SEAL | 1 | SN: F50003- |
|||
| ? | 37A-09-4A013 | WASHER | 1 | SN: F50003- |
|||
| ? | 42N-04-11530 | PIN | 1 | SN: F50003- |
|||
| ? | 42N-04-11520 | COVER | 1 | SN: F50003- |
|||
| ? | 37A-09-51006 | PIN, SAFETY | 1 | SN: F50003- |
|||
| ? | 21D-04-11380 | FUEL FILTER | 1 | SN: F50003- |
|||
| ? | 21D-09-66610 | ELBOW | 1 | SN: F50003- |
|||
| ? | 37B-09-15617 | • O-RING | 1 | SN: F50003- |
