| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6732-31-1100 | CRANKSHAFT ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6732-31-1110 | • CRANKSHAFT | 1 | SN: 21273646- |
|||
| ? | 6732-21-6150 | • PIN,DOWEL | 1 | SN: 21273646- |
|||
| ? | 6736-31-1210 | • GEAR,CRANKSHAFT | 1 | SN: 21273646- |
|||
| ? | STANDARD | ||||||
| ? | 6732-29-8110 | MAIN BEARING ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6732-21-8220 | • METAL,UPPER | 4 | SN: 21273646- |
|||
| ? | 6732-21-8180 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6732-21-8210 | • METAL,LOWER | 5 | SN: 21273646- |
|||
| ? | OVERSIZE 0.25MM | ||||||
| ? | 6732-28-8100 | MAIN BEARING ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-29-8110 | • METAL,UPPER | 4 | SN: 21273646- |
|||
| ? | 6736-29-8140 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-29-8130 | • METAL,LOWER | 5 | SN: 21273646- |
|||
| ? | OVERSIZE 0.50MM | ||||||
| ? | 6732-27-8100 | MAIN BEARING ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-28-8110 | • METAL,UPPER | 4 | SN: 21273646- |
|||
| ? | 6736-28-8120 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-29-8720 | • METAL,LOWER | 5 | SN: 21273646- |
|||
| ? | OVERSIZE 0.75MM | ||||||
| ? | 6732-26-8100 | MAIN BEARING ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-27-8110 | • METAL,UPPER | 4 | SN: 21273646- |
|||
| ? | 6736-27-8140 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-27-8130 | • METAL,LOWER | 5 | SN: 21273646- |
|||
| ? | OVERSIZE 1.00MM | ||||||
| ? | 6732-25-8100 | MAIN BEARING ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-26-8110 | • METAL,UPPER | 4 | SN: 21273646- |
|||
| ? | 6736-26-8140 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-26-8130 | • METAL,LOWER | 5 | SN: 21273646- |
|||
| ? | OVERSIZE 0.5MM{THRUST} | ||||||
| ? | 6736-29-8700 | THRUST METAL ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-29-8730 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-29-8720 | • METAL,LOWER | 1 | SN: 21273646- |
|||
| ? | OVERSIZE 1.0MM{THRUST} | ||||||
| ? | 6736-28-8700 | THRUST METAL ASS'Y | 1 | SN: 21273646- |
|||
| ? | 6736-28-8720 | • METAL,THRUST | 1 | SN: 21273646- |
|||
| ? | 6736-26-8130 | • METAL,LOWER | 1 | SN: 21273646- |
|||
| ? | SERVICE PARTS | ||||||
| ? | 6736-39-1220 | SLEEVE,FRONT | 1 | SN: 21273646- |
|||
| ? | 6736-39-1120 | SLEEVE,REAR | 1 | SN: 21273646- |
