| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6731-21-1010 | CYLINDER BLOCK A.,SERVICE | 1 | SN: 21273646- |
|||
| ? | 6731-21-1100 | • CYLINDER BLOCK A.,CYLINDER | 1 | SN: 21273646- |
|||
| ? | 6732-21-1410 | • BUSHING,CAMSHAFT | 1 | SN: 21273646- |
|||
| ? | 6732-21-1610 | • BOLT | 10 | SN: 21273646- |
|||
| ? | \5\6732-21-1210 | • CAP,MAIN | 5 | SN: 21273646- |
|||
| ? | 6736-21-1830 | • PLUG,EXPANSION | 4 | SN: 21273646- |
|||
| ? | 6736-21-1820 | • PLUG,EXPANSION | 2 | SN: 21273646- |
|||
| ? | 6732-21-1810 | • PLUG,EXPANSION | 3 | SN: 21273646- |
|||
| ? | 6732-21-1910 | • RING,DOWEL | 10 | SN: 21273646- |
|||
| ? | 6732-21-8110 | BLOCK SERVICE KIT,CYLINDER | 1 | SN: 21273646- |
|||
| ? | 6732-21-6140 | • RING,DOWEL | 2 | SN: 21273646- |
|||
| ? | 6732-21-1191 | • NOZZLE,PISTON COOLING | 4 | SN: 21273646- |
|||
| ? | 6732-21-1910 | • RING,DOWEL | 2 | SN: 21273646- |
|||
| ? | 6732-21-6120 | • PIN,DOWEL | 2 | SN: 21273646- |
|||
| ? | 6732-11-1910 | • PLUG | 1 | SN: 21273646- |
|||
| ? | 6732-11-1930 | • PLUG | 2 | SN: 21273646- |
|||
| ? | 6735-21-5530 | • PLUG,(FOR SHIPPING) | 1 | SN: 21273646- |
|||
| ? | 6732-21-6130 | • PLUG,EXPANSION | 1 | SN: 21273646- |
|||
| ? | 6732-21-5530 | • PLUG,EXPANSION | 1 | SN: 21273646- |
|||
| ? | 6732-21-6160 | • PLUG,EXPANSION | 1 | SN: 21273646- |
|||
| ? | 6732-21-1930 | • O-RING | 1 | SN: 21273646- |
|||
| ? | SERVICE PARTS | ||||||
| ? | 6736-29-1410 | BUSHING,CAMSHAFT ? NO.1 BORE | A/R | SN: 21273646- |
|||
| ? | 6736-29-1420 | BUSHING,CAMSHAFT ? NO.2 ?3 ?4 ?5 BORE | A/R | SN: 21273646- |
|||
| ? | \5\6732-21-1210 | CAP,MAIN | 5 | SN: 21273646- |
|||
| ? | 6736-29-2110 | LINER,SALVAGE (STD) | A/R | SN: 21273646- |
