| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6271-21-1000 | CYLINDER BLOCK ASSEMBLY | 1 | SN: 500001- |
|||
| ? | ☆ | • BLOCK, CYLINDER | 1 | SN: 514763- |
|||
| ? | ☆ | • BLOCK, CYLINDER | 1 | SN: 500001-514762 |
|||
| ? | \5\6204-29-1210 | • CAP, MAIN METAL, NO.1, 2, 3 ,4 | 4 | SN: 500001- |
|||
| ? | \5\6204-29-1220 | • CAP, MAIN METAL, NO.5 | 1 | SN: 500001- |
|||
| ? | 6204-21-1610 | • BOLT, MAIN CAP | 10 | SN: 500001- |
|||
| ? | 6141-21-1530 | • RING, DOWEL | 2 | SN: 500001- |
|||
| ? | 6206-21-1430 | • BUSHING, CAMSHAFT | 1 | SN: 500001- |
|||
| ? | 6206-21-1420 | • BUSHING, CAMSHAFT | 2 | SN: 500001- |
|||
| ? | 07046-42216 | • PLUG | 1 | SN: 500001- |
|||
| ? | 07046-42516 | • PLUG | 5 | SN: 500001- |
|||
| ? | 07046-43016 | • PLUG | 7 | SN: 500001- |
|||
| ? | 07046-44016 | • PLUG | 1 | SN: 500001- |
|||
| ? | 07042-70312 | • PLUG | 1 | SN: 500001- |
|||
| ? | 6215-81-9710 | • O-RING | 2 | SN: 504673- |
|||
| ? | 6215-81-9710 | • O-RING | 5 | SN: 500001-504672 |
|||
| ? | 6215-81-9510 | • PLUG | 2 | SN: 504673- |
|||
| ? | 6215-81-9510 | • PLUG | 5 | SN: 500001-504672 |
|||
| ? | 6204-51-1711 | • BUSHING, OIL PUMP | 1 | SN: 500001- |
|||
| ? | 6140-21-1130 | • BUSHING, DOWEL | 2 | SN: 500001- |
|||
| ? | 04020-00820 | • PIN, DOWEL | 2 | SN: 500001- |
|||
| ? | 04020-01228 | • PIN, DOWEL | 2 | SN: 500001- |
|||
| ? | 04025-00408 | • PIN, SPRING | 6 | SN: 500001- |
|||
| ? | 07046-41810 | • PLUG | 4 | SN: 500001- |
|||
| ? | 07043-70108 | • PLUG | 1 | SN: 500001- |
|||
| ? | 6136-52-1620 | • PIN, DOWEL, OIL PUMP | 1 | SN: 500001- |
|||
| ? | 6204-51-1620 | • SHAFT, OIL PUMP | 1 | SN: 500001- |
|||
| ? | 6207-21-1190 | • PIN | 4 | SN: 500001- |
