| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6271-11-1010 | HEAD ASSEMBLY | 1 | SN: 500001- |
|||
| ? | 6271-11-1100 | CYLINDER HEAD A., VALVE LESS | 1 | SN: 500001- |
|||
| ? | ☆ | • HEAD, CYLINDER | 1 | SN: 500001- |
|||
| ? | 6204-19-1310 | • GUIDE, VALVE | 8 | SN: 500001- |
|||
| ? | 6207-11-1431 | • SEAT, INTAKE VALVE (STD) | 4 | SN: 500001- |
|||
| ? | 6207-19-1431 | • SEAT, 0.25MM, INTAKE VALVE (OS) | 4 | SN: 500001- |
|||
| ? | 6207-18-1431 | • SEAT, 0.50MM, INTAKE VALVE (OS) | 4 | SN: 500001- |
|||
| ? | 6208-11-1440 | • SEAT, EXHAUST VALVE (STD) | 4 | SN: 500001- |
|||
| ? | 6208-19-1440 | • SEAT, 0.25MM, EXHAUST VALVE (OS) | 4 | SN: 500001- |
|||
| ? | 6208-18-1440 | • SEAT, 0.50MM, EXHAUST VALVE (OS) | 4 | SN: 500001- |
|||
| ? | 07046-41008 | • PLUG | 4 | SN: 500001- |
|||
| ? | 07046-41810 | • PLUG | 9 | SN: 500001- |
|||
| ? | 07046-42216 | • PLUG | 3 | SN: 500001- |
|||
| ? | 07046-42516 | • PLUG | 11 | SN: 500001- |
|||
| ? | 02720-40104 | • PLUG | 1 | SN: 500001- |
|||
| ? | 6207-41-4130 | VALVE, INTAKE | 4 | SN: 500001- |
|||
| ? | 6209-41-4210 | VALVE, EXHAUST | 4 | SN: 500001- |
|||
| ? | 6204-41-4510 | SEAT | 8 | SN: 500001- |
|||
| ? | 6204-41-4520 | COTTER | 16 | SN: 500001- |
|||
| ? | 6204-41-4410 | SPRING, VALVE | 8 | SN: 500001- |
|||
| ? | 6204-41-4541 | SEAL | 8 | SN: 500001- |
|||
| ? | 6204-41-4550 | CAP | 8 | SN: 500001- |
|||
| ? | 6204-11-1840 | GASKET | 1 | SN: 500001- |
|||
| ? | 6204-13-1610 | BOLT | 17 | SN: 500001- |
