| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6152-72-1280) | INJECTION PUMP ASS'Y | 1 | SN: 210001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3T8 TO A4010-H3T8. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105681-6010 | • TIMER ASS'Y | 1 | SN: 210001- |
|||
| ? | DK156800-2720 | • • HOUSING,TIMER | 1 | SN: 210001- |
|||
| ? | DK156801-6400 | • • FLANGE | 1 | SN: 210001- |
|||
| ? | DK156723-0300 | • • CAM,ECCENTRIC | 2 | SN: 210001- |
|||
| ? | DK156723-0400 | • • CAM,ECCENTRIC | 2 | SN: 210001- |
|||
| ? | DK156898-5120 | • • FLYWEIGHT ASS'Y | 1 | SN: 210001- |
|||
| ? | DK156802-9820 | • • • FLYWEIGHT | 2 | SN: 210001- |
|||
| ? | DK156807-1100 | • • • SEAT,SPRING | 4 | SN: 210001- |
|||
| ? | DK156807-0900 | • • • SEAT,SPRING | 4 | SN: 210001- |
|||
| ? | DK156893-5400 | • • • TIMER,SPRING | 4 | SN: 210001- |
|||
| ? | DK156809-0300 | • • • RING ? SNAP | 4 | SN: 210001- |
|||
| ? | DK156806-0900 | • • • PIN,PILOT | 2 | SN: 210001- |
|||
| ? | DK156728-0800 | • • • SHIM ? 0.1MM | A/R | SN: 210001- |
|||
| ? | DK156728-0900 | • • • SHIM ? 0.3MM | A/R | SN: 210001- |
|||
| ? | DK156728-1000 | • • • SHIM ? 0.5MM | A/R | SN: 210001- |
|||
| ? | DK156728-1100 | • • • SHIM ? 1.0MM | A/R | SN: 210001- |
|||
| ? | DK156728-2000 | • • • SHIM ? 0.4MM | A/R | SN: 210001- |
|||
| ? | DK156728-2100 | • • • SHIM ? 0.7MM | A/R | SN: 210001- |
|||
| ? | DK156808-0500 | • • • SPACER | 4 | SN: 210001- |
|||
| ? | DK156809-1520 | • • COVER | 1 | SN: 210001- |
|||
| ? | DK139648-0300 | • • SEAL | 1 | SN: 210001- |
|||
| ? | DK156315-0200 | • • O-RING | 1 | SN: 210001- |
|||
| ? | DK156322-0000 | • • WASHER,SPRING | 1 | SN: 210001- |
|||
| ? | DK134325-0800 | • • NUT | 1 | SN: 210001- |
|||
| ? | DK029331-0190 | • • GASKET | 1 | SN: 210001- |
|||
| ? | DK156316-0000 | • • PLUG | 1 | SN: 210001- |
|||
| ? | DK156314-0600 | • • CAP | 1 | SN: 210001- |
|||
| ? | DK156319-0200 | • • GASKET | 1 | SN: 210001- |
