| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20G-62-K1730 | TUBE | 1 | SN: K20001- |
|||
| ? | 20G-62-K1730 | TUBE,(EXCEPT GERMANY) | 1 | SN: K20001- |
|||
| ? | 20G-62-K3520 | TUBE,(FOR GERMANY) | 1 | SN: K20001- |
|||
| ? | 07099-00617 | HOSE | 1 | SN: K20001- |
|||
| ? | 07099-00617 | HOSE,(EXCEPT GERMANY) | 1 | SN: K20001- |
|||
| ? | 20G-62-K3540 | HOSE,(FOR GERMANY) | 1 | SN: K20001- |
|||
| ? | 07371-30640 | FLANGE,(EXCEPT GERMANY) | 12 | SN: K20001- |
|||
| ? | 07371-30640 | FLANGE,(FOR GERMANY) | 10 | SN: K20001- |
|||
| ? | 07000-13025 | O-RING,(EXCEPT GERMANY) | 6 | SN: K20001- |
|||
| ? | 07000-13025 | O-RING,(FOR GERMANY) | 5 | SN: K20001- |
|||
| ? | 07372-21035 | BOLT,(EXCEPT GERMANY) | 24 | SN: K20001- |
|||
| ? | 07372-21035 | BOLT,(FOR GERMANY) | 20 | SN: K20001- |
|||
| ? | 01643-51032 | WASHER,(EXCEPT GERMANY) | 24 | SN: K20001- |
|||
| ? | 01643-51032 | WASHER,(FOR GERMANY) | 20 | SN: K20001- |
|||
| ? | 21K-62-34310 | FLANGE,(FOR GERMANY) | 1 | SN: K20001- |
|||
| ? | 07000-03030 | O-RING,(FOR GERMANY) | 1 | SN: K20001- |
|||
| ? | 07372-21030 | BOLT,(FOR GERMANY) | 4 | SN: K20001- |
|||
| ? | 01643-51032 | WASHER,(FOR GERMANY) | 4 | SN: K20001- |
|||
| ? | 20G-60-K1740 | VALVE,(FOR GERMANY) | 1 | SN: K20001- |
|||
| ? | 07002-12434 | O-RING,(FOR GERMANY) | 2 | SN: K20001- |
|||
| ? | 20G-62-K1870 | BLOCK | 1 | SN: K20001- |
|||
| ? | 01010-51295 | BOLT | 2 | SN: K20001- |
|||
| ? | 01643-31232 | WASHER | 2 | SN: K20001- |
|||
| ? | 21P-62-K1530 | HOSE | 2 | SN: K20001- |
|||
| ? | 07371-30640 | FLANGE,SPLIT | 8 | SN: K20001- |
|||
| ? | 07000-13025 | O-RING | 4 | SN: K20001- |
|||
| ? | 07372-21035 | BOLT | 16 | SN: K20001- |
|||
| ? | 01643-51032 | WASHER | 16 | SN: K20001- |
|||
| ? | 21K-62-35270 | CUSHION | 2 | SN: K20001- |
|||
| ? | 203-70-53381 | PLATE | 2 | SN: K20001- |
|||
| ? | 01010-51030 | BOLT | 4 | SN: K20001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: K20001- |
|||
| ? | 201-973-6740 | SEAT | 2 | SN: K20001- |
|||
| ? | 201-973-6730 | CLAMP | 2 | SN: K20001- |
|||
| ? | 01010-51060 | BOLT | 4 | SN: K20001- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: K20001- |
