| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20G-03-K1180 | RADIATOR ASSEMBLY,(WITH OIL COOLER) | 1 | SN: K32001-K35000 |
|||
| ? | 21P-03-K1320 | • RADIATOR CORE ASSEMBLY | 1 | SN: K30001-K35000 |
|||
| ? | 205-03-71280 | • CAP ASSEMBLY | 1 | SN: K30001-K35000 |
|||
| ? | 205-03-62660 | • PLUG | 1 | SN: K30001-K35000 |
|||
| ? | 07000-01007 | • • O-RING | 1 | SN: K30001-K35000 |
|||
| ? | 203-03-41411 | • HOSE | 1 | SN: K30001-K35000 |
|||
| ? | 20Y-03-11330 | • CLIP | 1 | SN: K30001-K35000 |
|||
| ? | 01435-20816 | • BOLT | 8 | SN: K30001-K35000 |
|||
| ? | 21P-03-K2191 | • SEAL | 1 | SN: K30001-K32009 |
|||
| ? | 20G-03-K1340 | • FRAME | 1 | SN: K30001-K35000 |
|||
| ? | 21P-03-K2211 | • SEAL | 2 | SN: K30001-K35000 |
|||
| ? | 20G-03-K1390 | • OIL COOLER ASSEMBLY | 1 | SN: K30001-K35000 |
|||
| ? | 21P-03-K2221 | • SEAL | 1 | SN: K30001-K35000 |
|||
| ? | 01010-81225 | • BOLT | 4 | SN: K30001-K35000 |
|||
| ? | 01643-31232 | • WASHER | 4 | SN: K30001-K35000 |
|||
| ? | 20Y-03-21430 | • SEAL | 2 | SN: K30001-K35000 |
|||
| ? | 20G-03-K1360 | • NET | 1 | SN: K30001-K35000 |
|||
| ? | 20G-03-K1370 | • NET | 1 | SN: K30001-K35000 |
|||
| ? | 01434-10616 | • BOLT, WING | 3 | SN: K30001-K35000 |
|||
| ? | 01643-30823 | • WASHER | 3 | SN: K30001-K35000 |
|||
| ? | 21P-03-K2181 | • SEAL | 2 | SN: K30001-K35000 |
|||
| ? | 20G-03-K1330 | • SHROUD | 1 | SN: K32001-K35000 |
|||
| ? | 01435-20816 | • BOLT | 8 | SN: K32001-K35000 |
|||
| ? | 20G-03-K1350 | • PIPE | 1 | SN: K32001-K35000 |
|||
| ? | 07000-13032 | • O-RING | 1 | SN: K32001-K35000 |
|||
| ? | 01010-81040 | • BOLT | 2 | SN: K32001-K35000 |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: K32001-K35000 |
|||
| ? | 07283-24340 | • CLAMP | 1 | SN: K32001-K35000 |
|||
| ? | 01599-01011 | • NUT | 2 | SN: K32001-K35000 |
|||
| ? | 01643-31032 | • WASHER | 2 | SN: K32001-K35000 |
|||
| ? | 20G-03-K1170 | SHEET | 1 | SN: K32001-K35000 |
|||
| ? | 20G-03-K1450 | SHEET | 1 | SN: K32010-K35000 |
