| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ND448800-5222 | UNIT ASS'Y,COOLING | 1 | SN: K40001- |
|||
| ? | ND245450-2221 | • CASE,COOLING | 1 | SN: K40001- |
|||
| ? | ND245450-1721 | • CASE,COOLING | 1 | SN: K40001- |
|||
| ? | ND116569-5010 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND447600-4970 | • EVAPORATOR | 1 | SN: K40001- |
|||
| ? | ND949142-0030 | • • O-RING | 2 | SN: K40001- |
|||
| ? | ND116120-7990 | • CORE ASS'Y,HEATER | 1 | SN: K40001- |
|||
| ? | ND447500-1390 | • VALVE,EXPANSION | 1 | SN: K40001- |
|||
| ? | ND949046-2150 | • BOLT | 2 | SN: K40001- |
|||
| ? | ND446870-5650 | • TUBE,ACCESSORY | 1 | SN: K40001- |
|||
| ? | ND949142-0030 | • • O-RING | 1 | SN: K40001- |
|||
| ? | ND949142-0010 | • • O-RING | 2 | SN: K40001- |
|||
| ? | ND077500-0710 | • THERMISTOR | 1 | SN: K40001- |
|||
| ? | ND246690-2840 | • CLAMP | 2 | SN: K40001- |
|||
| ? | ND116650-8800 | • DOOR ASS'Y | 1 | SN: K40001- |
|||
| ? | ND116650-8820 | • DOOR ASS'Y | 1 | SN: K40001- |
|||
| ? | ND116650-8840 | • DOOR ASS'Y | 1 | SN: K40001- |
|||
| ? | ND116640-4652 | • DAMPER ASS'Y | 1 | SN: K40001- |
|||
| ? | ND443440-0030 | • SWITCH,PRESSURE | 1 | SN: K40001- |
|||
| ? | ND949142-0040 | • • O-RING | 1 | SN: K40001- |
|||
| ? | ND446830-3880 | • TUBE | 1 | SN: K40001- |
|||
| ? | ND446810-9520 | • TUBE,SUCTION | 1 | SN: K40001- |
|||
| ? | ND949142-0030 | • • O-RING | 1 | SN: K40001- |
|||
| ? | ND146678-4930 | • PACKING | 1 | SN: K40001- |
|||
| ? | ND949321-9940 | • GROMMET | 1 | SN: K40001- |
|||
| ? | ND246770-6990 | • CLAMP,PIPING | 1 | SN: K40001- |
|||
| ? | ND017231-1400 | • CLAMP | 1 | SN: K40001- |
|||
| ? | ND017660-3490 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND170400-4310 | • SENSOR ASS'Y,THERMO | 1 | SN: K40001- |
|||
| ? | ND146690-6020 | • CLAMP | 1 | SN: K40001- |
|||
| ? | ND246634-6010 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND499300-2051 | • I.C. POWER | 1 | SN: K40001- |
|||
| ? | ND063700-7200 | • SERVO MOTOR ASS'Y | 2 | SN: K40001- |
|||
| ? | ND063700-7210 | • SERVO MOTOR ASS'Y | 1 | SN: K40001- |
|||
| ? | ND116569-5020 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND116682-0930 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND116682-0960 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND116662-4850 | • SHAFT | 1 | SN: K40001- |
|||
| ? | ND116569-5030 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND116682-0940 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND116682-0951 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND116569-5041 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND116569-5051 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND116662-4860 | • SHAFT | 1 | SN: K40001- |
|||
| ? | ND116569-5062 | • PLATE | 1 | SN: K40001- |
|||
| ? | ND116682-0920 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND116682-0910 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND949008-0460 | • SCREW,TAPPING | 4 | SN: K40001- |
|||
| ? | 17M-911-3290 | • CLAMP | 2 | SN: K40001- |
|||
| ? | ND146535-1311 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND146535-0411 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND146525-6070 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND91310-03081 | • SCREW,WASHER | 4 | SN: K40001- |
|||
| ? | ND949001-1730 | • SCREW,TAPPING | 23 | SN: K40001- |
|||
| ? | ND90930-05121 | • SCREW,TAPPING | 1 | SN: K40001- |
|||
| ? | ND90930-06141 | • SCREW,TAPPING | 8 | SN: K40001- |
|||
| ? | ND146535-0421 | • BRACKET | 1 | SN: K40001- |
|||
| ? | ND90930-05161 | • SCREW,TAPPING | 2 | SN: K40001- |
|||
| ? | ND116682-3440 | • LEVER | 1 | SN: K40001- |
|||
| ? | ND017730-8380 | • LEVER,CONTROL | 1 | SN: K40001- |
|||
| ? | ND116660-2770 | • DOOR ASS'Y | 1 | SN: K40001- |
|||
| ? | ND146698-6930 | • PACKING | 1 | SN: K40001- |
|||
| ? | ND146698-6950 | • PACKING | 1 | SN: K40001- |
|||
| ? | ND146698-8480 | • PACKING | 1 | SN: K40001- |
|||
| ? | ND146637-5650 | • PACKING | 2 | SN: K40001- |
|||
| ? | ND146647-0712 | • PACKING | 1 | SN: K40001- |
|||
| ? | ND146647-3880 | • PACKING | 2 | SN: K40001- |
