| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (20K-60-31111) | MOTOR ASS'Y,TRAVEL | 1 | SN: K40001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-05A0. | ||||||
| ? | (20K-60-31830) | • CONTROL ASS'Y | 1 | SN: K40001- |
|||
| ? | 20K-60-31980 | • • CONTROL ASS'Y | 1 | SN: K40001- |
|||
| ? | 20E-60-K4520 | • • • HOUSING,CONTROL | 1 | SN: K40001- |
|||
| ? | 20G-60-K2640 | • • • BUSHING,CONTROL | 1 | SN: K40001- |
|||
| ? | 20K-20-32290 | • • • PISTON,CONTROL | 1 | SN: K40001- |
|||
| ? | 20G-60-K4920 | • • • BUSHING,ADJUSTING | 1 | SN: K40001- |
|||
| ? | 20K-60-32310 | • • • COLLAR | 1 | SN: K40001- |
|||
| ? | 20K-60-32320 | • • • COLLAR | 1 | SN: K40001- |
|||
| ? | 20G-60-K4290 | • • • SPRING | 1 | SN: K40001- |
|||
| ? | 20K-60-32330 | • • • SPRING | 1 | SN: K40001- |
|||
| ? | 20E-60-K4580 | • • • SPRING | 1 | SN: K40001- |
|||
| ? | 20G-60-K4940 | • • • O-RING | 1 | SN: K40001- |
|||
| ? | 20G-60-K4950 | • • • SCREW | 4 | SN: K40001- |
|||
| ? | 20G-60-K4320 | • • • SCREW | 1 | SN: K40001- |
|||
| ? | 20G-60-K2730 | • • • RING,RETAINING | 1 | SN: K40001- |
|||
| ? | 20G-60-K1490 | • • • STUD | 1 | SN: K40001- |
|||
| ? | 20G-60-K4960 | • • • PIN | 1 | SN: K40001- |
|||
| ? | 20G-60-K1520 | • • • NUT,LOCK | 1 | SN: K40001- |
|||
| ? | 20G-60-K2750 | • • • PIN | 1 | SN: K40001- |
|||
| ? | 20G-60-K2590 | • • • PIN | 1 | SN: K40001- |
|||
| ? | 20G-60-K2760 | • • • DISC,RETAINING | 1 | SN: K40001- |
|||
| ? | 20K-60-31990 | • • COVER ASS'Y | 1 | SN: K40001- |
|||
| ? | 20E-60-K6680 | • • • COVER | 1 | SN: K40001- |
|||
| ? | 20K-60-32340 | • • • SCREW | 1 | SN: K40001- |
|||
| ? | 20E-60-K6690 | • • • SCREW | 4 | SN: K40001- |
|||
| ? | 20G-60-K5020 | • • • O-RING | 1 | SN: K40001- |
|||
| ? | 20G-60-K4320 | • • • SCREW | 1 | SN: K40001- |
