| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-7G-01040 | MOTOR ASS'Y | 1 | SN: K40001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0. | ||||||
| ? | 706-7G-03040 | • MOTOR SUB ASS'Y | 1 | SN: K40001- |
|||
| ? | (★706-7G-41110) | • • CASE | 1 | SN: K40001- |
|||
| ? | (★706-7G-71130) | • • HOUSING | 1 | SN: K40001- |
|||
| ? | (★706-7G-40010) | • • BEARING | 1 | SN: K40001- |
|||
| ? | (★706-75-42820) | • • PIN,DOWEL | 1 | SN: K40001- |
|||
| ? | 709-25-11650 | • • VALVE,CHECK | 2 | SN: K40001- |
|||
| ? | 709-25-11361 | • • SPRING | 2 | SN: K40001- |
|||
| ? | 709-25-11640 | • • PLUG | 2 | SN: K40001- |
|||
| ? | 07000-12020 | • • O-RING | 2 | SN: K40001- |
|||
| ? | 706-75-74540 | • • VALVE | 2 | SN: K40001- |
|||
| ? | 706-7G-71550 | • • SPRING | 2 | SN: K40001- |
|||
| ? | 706-75-74850 | • • PLUG | 2 | SN: K40001- |
|||
| ? | 07002-13334 | • • O-RING | 2 | SN: K40001- |
|||
| ? | (★706-75-42370) | • • O-RING | 1 | SN: K40001- |
|||
| ? | 01252-61245 | • • BOLT | 10 | SN: K40001- |
