| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-2L-00202) | PUMP ASS'Y | 1 | SN: K40014- |
|||
| ? | (708-2L-00200) | PUMP ASS'Y | 1 | SN: K40001-K40013 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-11A0. | ||||||
| ? | (708-2L-01203) | • PUMP SUB ASS'Y | 1 | SN: K40014- |
|||
| ? | (708-2L-01201) | • PUMP SUB ASS'Y | 1 | SN: K40001-K40013 |
|||
| ? | (★708-2L-44120) | • • SLIDER | 1 | SN: K40001- |
|||
| ? | (★708-2L-06542) | • • VALVE ASS'Y,PC | 1 | SN: K40001- |
|||
| ? | (★708-2L-06551) | • • • PISTON ASS'Y,SERVO | 1 | SN: K40001- |
|||
| ? | ☆ | • • • • PISTON,SERVO | 1 | SN: K40001- |
|||
| ? | ☆ | • • • • SCREW | 7 | SN: K40001- |
|||
| ? | (★708-2G-15320) | • • • SEAL | 1 | SN: K40001- |
|||
| ? | (★708-2L-45131) | • • • PLUG | 1 | SN: K40001- |
|||
| ? | (★708-2L-35760) | • • • BALL | 1 | SN: K40001- |
|||
| ? | (★708-2L-35770) | • • • PLUG | 1 | SN: K40001- |
|||
| ? | (★708-2L-35690) | • • • SEAL | 3 | SN: K40001- |
|||
| ? | (★708-2L-35170) | • • • PIN | 1 | SN: K40001- |
|||
| ? | (★708-2L-35860) | • • • SPOOL | 1 | SN: K40001- |
|||
| ? | (★708-2G-15290) | • • • RETAINER | 1 | SN: K40001- |
|||
| ? | (★708-2L-35641) | • • • SEAT | 1 | SN: K40001- |
|||
| ? | (★708-2L-44180) | • • • SPRING | 1 | SN: K40001- |
|||
| ? | (★708-2L-44190) | • • • SPRING | 1 | SN: K40001- |
|||
| ? | (★708-2L-35650) | • • • SEAT | 1 | SN: K40001- |
|||
| ? | (★708-2L-44140) | • • • SPRING | 1 | SN: K40001- |
|||
| ? | (★708-2L-44151) | • • • SCREW | 1 | SN: K40001- |
|||
| ? | (★07000-B3038) | • • • O-RING | 1 | SN: K40001- |
|||
| ? | (★708-2G-15230) | • • • RING | 1 | SN: K40001- |
|||
| ? | (★708-2G-15260) | • • • SEAL | 1 | SN: K40001- |
|||
| ? | (★708-2L-35660) | • • • PLUG | 1 | SN: K40001- |
|||
| ? | (★07000-B2010) | • • • O-RING | 1 | SN: K40001- |
|||
| ? | (★07000-B2050) | • • • O-RING | 1 | SN: K40001- |
|||
| ? | (★708-2G-15310) | • • • RING | 1 | SN: K40001- |
|||
| ? | (★708-2L-44161) | • • • COVER | 1 | SN: K40001- |
|||
| ? | (★01580-10806) | • • • NUT | 1 | SN: K40001- |
|||
| ? | (★708-2L-35540) | • • • NUT | 1 | SN: K40001- |
|||
| ? | (★708-2G-15330) | • • • RING,WIRE | 1 | SN: K40001- |
|||
| ? | (★01252-61645) | • • BOLT | 4 | SN: K40001- |
