| Наименование | Страница | Код страницы |
|---|---|---|
| MAIN VALVE (5-SPOOL) (1/5) | 016046 | Y1665-01A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (709-15-94200) | CONTROL VALVE | 1 | SN: K50001- |
Y1665-01A0 | ||
| ? | 209-64-16311 | TEE | 1 | SN: K50001- |
|||
| ? | 07042-30108 | PLUG | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 21N-64-36440 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 21N-64-36440 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 209-64-16721 | TEE | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 02782-10315 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 209-64-16721 | TEE | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 21N-64-36440 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 209-64-16721 | TEE | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 209-64-16721 | TEE | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 02782-10315 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 11Y-62-12510 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 02782-10312 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | 11Y-62-12510 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
