| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-7T-00381 | SWING MOTOR, ASSY. | 1 | SN: 0000001- |
|||
| ? | 708-7T-01150 | • MOTOR, ASSY. | 1 | SN: 0000001- |
|||
| ? | (★708-7T-11240) | • • CASE, MOTOR | 1 | SN: 0000001- |
|||
| ? | (★708-7T-11640) | • • COVER | 1 | SN: 0000001- |
|||
| ? | (★708-7T-51210) | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★720-68-19610) | • • PIN | 2 | SN: 0000001- |
|||
| ? | (★01010-81250) | • • BOLT | 4 | SN: 0000001- |
|||
| ? | (★708-7T-12220) | • • SHAFT | 1 | SN: 0000001- |
|||
| ? | (★708-7T-12240) | • • BEARING | 1 | SN: 0000001- |
|||
| ? | (★708-7T-12250) | • • BEARING | 1 | SN: 0000001- |
|||
| ? | (★708-7T-05020) | • • SPACER KIT | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 1.6 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 1.7 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 1.8 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 1.9 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 2.0 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 2.1 mm | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • SPACER 2.2 mm | 1 | SN: 0000001- |
|||
| ? | 708-7T-12230 | • • GASKET | 1 | SN: 0000001- |
|||
| ? | 04065-04518 | • • RING, SNAP | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13140) | • • BLOCK, CYLINDER | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13270) | • • TIMING PLATE | 1 | SN: 0000001- |
|||
| ? | (★720-68-19610) | • • PIN | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13540) | • • PIN | 3 | SN: 0000001- |
|||
| ? | (★708-7T-13530) | • • WASHER | 2 | SN: 0000001- |
|||
| ? | (★708-7T-13570) | • • SPRING | 1 | SN: 0000001- |
|||
| ? | (★04065-03815) | • • RING, SNAP | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13510) | • • GUIDE | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13342) | • • PLATE | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13611) | • • PISTON, ASSY. | 7 | SN: 0000001- |
|||
| ? | (★708-7T-13421) | • • THRUST PLATE | 1 | SN: 0000001- |
|||
| ? | (★708-7T-13710) | • • SPACER | 1 | SN: 0000001- |
|||
| ? | (★708-7T-52512) | • • DISK | 3 | SN: 0000001- |
|||
| ? | (★708-7T-15120) | • • FRICTION DISK | 2 | SN: 0000001- |
|||
| ? | (★708-7T-15140) | • • PISTON | 1 | SN: 0000001- |
|||
| ? | (★07000-12130) | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★708-7T-55220) | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★708-7T-15150) | • • SPRING | 4 | SN: 0000001- |
