| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-1W-00310) | PUMP, ASSY. | 1 | SN: 0000001- |
|||
| ? | (708-1W-01310) | • HYDRAULIC PUMP, ASSY. | 1 | SN: 0000001- |
|||
| ? | ★708-1W-04110 | • • CASE, ASSY. | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • CASE, PUMP | 1 | SN: 0000001- |
|||
| ? | ☆ | • • • PLUG | 1 | SN: 0000001- |
|||
| ? | 07044-12412 | • • PLUG | 1 | SN: 0000001- |
|||
| ? | 708-1W-28910 | • • O-RING | 1 | SN: 0000001- |
|||
| ? | 04530-11018 | • • EYE-BOLT | 1 | SN: 0000001- |
|||
| ? | 720-68-19870 | • • PLUG | 1 | SN: 0000001- |
|||
| ? | 708-2L-23940 | • • O-RING | 1 | SN: 0000001- |
|||
| ? | 706-8E-14191 | • • PLUG | 1 | SN: 0000001- |
|||
| ? | 07002-11823 | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★708-1W-24150) | • • PISTON | 1 | SN: 0000001- |
|||
| ? | (★708-1W-24450) | • • SLIDER | 1 | SN: 0000001- |
|||
| ? | (★708-1W-24250) | • • SCREW | 1 | SN: 0000001- |
|||
| ? | 708-1W-28910 | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★708-1W-24311) | • • SCREW | 1 | SN: 0000001- |
|||
| ? | 708-1W-28930 | • • O-RING | 1 | SN: 0000001- |
|||
| ? | ★708-1W-24350 | • • SPRING | 1 | SN: 0000001- |
|||
| ? | (★708-1W-25840) | • • LINK | 1 | SN: 0000001- |
|||
| ? | (★708-1W-26132) | • • PIN | 1 | SN: 0000001- |
|||
| ? | (★708-1W-26113) | • • COVER | 1 | SN: 0000001- |
|||
| ? | (★07000-03045) | • • O-RING | 1 | SN: 0000001- |
|||
| ? | (★01010-80830) | • • BOLT | 2 | SN: 0000001- |
|||
| ? | (★01643-30823) | • • WASHER | 2 | SN: 0000001- |
|||
| ? | (★708-1W-26210) | • • PIN | 1 | SN: 0000001- |
|||
| ? | (★708-1W-26221) | • • SLIDER | 1 | SN: 0000001- |
|||
| ? | (★708-1W-26230) | • • WASHER | 1 | SN: 0000001- |
|||
| ? | 01580-10605 | • • NUT | 1 | SN: 0000001- |
|||
| ? | (708-1W-04640) | • • PC VALVE, ASSY. | 1 | SN: 0000001- |
|||
| ? | (708-1W-25740) | • • ORIFICE | 1 | SN: 0000001- |
|||
| ? | (708-1W-04830) | • • LS VALVE, ASSY. | 1 | SN: 0000001- |
