| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (21D-54-12301) | OPERATOR'S CAB, ASSY. | 1 | SN: 0000001- |
|||
| ? | 21D-54-13430 | • SEAL | 1 | SN: 0000001- |
|||
| ? | 21D-54-13661 | • FRAME, FRONT | 1 | SN: 0000001- |
|||
| ? | 21D-54-13680 | • SEAL, FRONT UPPER | 1 | SN: 0000001- |
|||
| ? | 21D-54-13670 | • GLASS, FRONT, UPPER | 1 | SN: 0000001- |
|||
| ? | 21D-54-13440 | • GLASS, FRONT, LOWER | 1 | SN: 0000001- |
|||
| ? | 21D-54-13630 | • BLOCK | 2 | SN: 0000001- |
|||
| ? | 21D-54-13640 | • RABBET | 2 | SN: 0000001- |
|||
| ? | 21D-54-13650 | • GASKET | 2 | SN: 0000001- |
|||
| ? | 01010-50816 | • BOLT | 2 | SN: 0000001- |
|||
| ? | 01643-30823 | • WASHER | 22 | SN: 0000001- |
|||
| ? | 21D-54-13731 | • LEVER, R.H. | 1 | SN: 0000001- |
|||
| ? | 21D-54-13741 | • LEVER, L.H. | 1 | SN: 0000001- |
|||
| ? | 21D-54-13790 | • CYLINDER | 2 | SN: 0000001- |
|||
| ? | 21D-09-23160 | • NUT | 4 | SN: 0000001- |
|||
| ? | 21D-54-13761 | • PIN | 2 | SN: 0000001- |
|||
| ? | 21D-54-13770 | • WASHER | 6 | SN: 0000001- |
|||
| ? | 01010-51012 | • BOLT | 4 | SN: 0000001- |
|||
| ? | 21D-54-13780 | • COVER | 4 | SN: 0000001- |
|||
| ? | 21D-54-13750 | • BUSHING | 6 | SN: 0000001- |
|||
| ? | 21D-54-13690 | • BUSHING | 2 | SN: 0000001- |
|||
| ? | 21D-54-13480 | • SPRING | 2 | SN: 0000001- |
|||
| ? | 21D-54-13720 | • LEVER | 2 | SN: 0000001- |
|||
| ? | 21D-54-13710 | • PIN | 2 | SN: 0000001- |
|||
| ? | 21D-54-14120 | • STRIKER | 2 | SN: 0000001- |
|||
| ? | 21D-54-14130 | • SHIM | 2 | SN: 0000001- |
|||
| ? | 01010-50616 | • BOLT | 4 | SN: 0000001- |
|||
| ? | 21D-09-73490 | • SPRING WASHER | 4 | SN: 0000001- |
|||
| ? | 01643-30623 | • WASHER | 4 | SN: 0000001- |
|||
| ? | 21D-54-13590 | • BLOCK | 2 | SN: 0000001- |
|||
| ? | 21D-54-13610 | • GASKET | 4 | SN: 0000001- |
|||
| ? | 21D-54-13620 | • SPACER | 2 | SN: 0000001- |
|||
| ? | 01010-50825 | • BOLT | 4 | SN: 0000001- |
|||
| ? | 21D-54-13450 | • LATCH ASSY., R.H. | 1 | SN: 0000001- |
A | ||
| ? | 21D-54-13520 | • LATCH ASSY., L.H. | 1 | SN: 0000001- |
B | ||
| ? | 21D-54-13530 | • • LATCH | 1 | SN: 0000001- |
|||
| ? | 21D-54-13480 | • • SPRING | 1 | SN: 0000001- |
|||
| ? | 21D-54-13460 | • • PIN | 1 | SN: 0000001- |
|||
| ? | 21D-54-13470 | • • SLEEVE | 1 | SN: 0000001- |
|||
| ? | 21D-54-13490 | • • PIN | 1 | SN: 0000001- |
|||
| ? | 21D-54-13510 | • • KNOB | 1 | SN: 0000001- |
|||
| ? | 21D-54-14670 | • PLATE | 1 | SN: 0000001- |
|||
| ? | 21D-54-14680 | • HANDLE, R.H. | 1 | SN: 0000001- |
|||
| ? | 21D-54-14690 | • HANDLE, L.H. | 1 | SN: 0000001- |
|||
| ? | 01010-50820 | • BOLT | 4 | SN: 0000001- |
|||
| ? | 21D-09-74460 | • SPRING WASHER | 4 | SN: 0000001- |
|||
| ? | 21D-09-86190 | • COVER | 4 | SN: 0000001- |
|||
| ? | 01580-10806 | • NUT | 4 | SN: 0000001- |
|||
| ? | 21D-54-14710 | • PIN | 2 | SN: 0000001- |
|||
| ? | 21D-54-12110 | KNOB | 2 | SN: 0000001- |
