| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (21D-14-10020) | TRANSMISSION, ASSY. | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11110 | • BEARING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-23-11970 | • PLUG | 1 | TRSN: PITA509404- |
|||
| ? | 21D-23-11960 | • WASHER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11120 | • COVER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11130 | • GEAR | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11150 | • BEARING | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11160 | • SPACER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-09-83130 | • RING, SNAP | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11890 | • SHIM | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11140 | • SELECTOR SHAFT | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11180 | • SLIDE BLOCK | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11170 | • GEAR, RING | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11190 | • CHANGE SELECTOR | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11210 | • GUIDE, TUBE | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11220 | • GEAR | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11230 | • BEARING | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11240 | • RING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11250 | • GEAR | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11260 | • PIN | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11270 | • PROTECTION | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11280 | • SWITCH | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11290 | • WASHER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-09-69280 | • O-RING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11310 | • HOUSING | 1 | TRSN: PITA509404-YITA740046 |
A | ||
| ? | 21D-14-11311 | • HOUSING | 1 | TRSN: YITA740047- |
B | ||
| ? | 21D-14-11330 | • SENSOR, REVOLUTION | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11320 | • WASHER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11340 | • INLET SHAFT | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11350 | • SHIM, 0.100 mm | A/R | TRSN: PITA509404- |
A | ||
| ? | 21D-14-11360 | • SHIM, 0.200 mm | A/R | TRSN: PITA509404- |
B | ||
| ? | 21D-14-11370 | • BEARING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11380 | • SHIM | 2 | TRSN: PITA509404- |
|||
| ? | 21D-14-11390 | • O-RING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-09-83120 | • RING | 1 | TRSN: PITA509404- |
|||
| ? | 21D-14-11410 | • COVER | 1 | TRSN: PITA509404- |
|||
| ? | 21D-09-74500 | • SPRING WASHER | 4 | TRSN: PITA509404- |
|||
| ? | 01010-51230 | • BOLT | 4 | TRSN: PITA509404- |
