| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-06-43110 | Light Assembly, Head | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 424-06-23230 | • Bulb, 75/70watt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 23S-06-54121 | • Lens Assembly | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 424-06-43221 | Lamp | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 41G-06-13210 | • Lens,Front | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 41G-06-13220 | • Lens,Rear | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 41G-06-13230 | • Bulb, 5watt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 08105-12420 | • Bulb, 25watt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01220-40425 | • Screw | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 08037-02512 | Grommet | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-06-43531 | Cover,LHS | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-06-43541 | Cover,RHS | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-54-13470 | Spacer | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 419-43-17930 | Cushion | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 415-64-13130 | Cushion | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 421-03-31590 | Washer | 12 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-D1245 | Bolt | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-06-43120 | Wire Harness | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 04434-50610 | Clip | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81016 | Bolt | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31032 | Washer | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-06-23190 | Plate | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-D0612 | Bolt | 10 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-70623 | Washer | 10 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-06-43511 | Support,LHS | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-06-43521 | Support,RHS | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81025 | Bolt | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31032 | Washer | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 09415-03614 | Cap | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
