| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 01583-11408 | Nut | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38221 | Hose, L=380mm, Blue-Red | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 11Y-62-12170 | Elbow | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 02896-11008 | O-ring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07002-02034 | O-ring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 8255-62-4370 | Union | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07002-02034 | O-ring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 02896-11008 | O-ring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38231 | Hose, L=380mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 20Y-62-18910 | Bolt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07000-12018 | O-ring | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07002-01423 | O-ring | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38243 | Hose, L=300mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01583-11408 | Nut | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38253 | Hose, L=300mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38262 | Hose, L=300mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38272 | Hose, L=300mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 20Y-62-18890 | Bolt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07000-12015 | O-ring | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-43-38282 | Hose, L=330mm | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01583-11408 | Nut | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31445 | Washer | 12 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
