| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-46-11220 | Retainer | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11330 | Shim, T=0.5mm | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11340 | Shim, T=0.1.mm | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11230 | Seal, Dust | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81030 | Bolt | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31032 | Washer | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11120 | Bearing | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11210 | Spacer | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-33110 | Bearing | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11260 | Ring | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11151 | Pin | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11180 | Spacer | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11160 | Washer | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01597-02419 | Nut, Flanged | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11190 | Shim, T=0.4mm | 10 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81230 | Bolt | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31232 | Washer | 4 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07020-00000 | Fitting, Grease | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11240 | Pin | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-46-11270 | Washer | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 424-46-11130 | Bushing | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81230 | Bolt | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 07020-00900 | Fitting, Grease | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
