| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-64-25020 | Valve Assembly, Priority | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | • Housing | 1 | SN: C10001- KIT-FLAG: _- SCC: C1 SERIALNO: C10001- |
||||
| ? | • Spool | 1 | SN: C10001- KIT-FLAG: _- SCC: C1 SERIALNO: C10001- |
||||
| ? | 416-64-15230 | • Spring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-64-25330 | • Valve Assembly | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-64-25320 | • O-ring | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 416-64-15250 | • Plug | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 416-64-15260 | • O-ring | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 416-64-15270 | • Plug | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-64-35513 | Bracket | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81665 | Bolt | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31645 | Washer | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 418-64-35524 | Bracket | 1 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-62-31170 | Cushion | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-62-31180 | Cushion | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 417-54-13470 | Spacer | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 419-43-17920 | Washer | 6 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-81255 | Bolt | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-31232 | Washer | 3 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01010-80885 | Bolt | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
|||
| ? | 01643-30823 | Washer | 2 | SN: C10001- KIT-FLAG: _- SCC: SERIALNO: C10001- |
