Содержание Excavators Komatsu PC360LC-10 S/N K60001-UP(PC360L2U)
Cab and Floor Frame Group, with Air Suspension Operatorґs Seat, 1-attachment Pedal, KUK, PPC Valve for Attachment(K016030 : K1110-003030)
Номер на схеме Каталожный номер Название Количество Детали
? 702-16-04290 Valve, Pilot 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • Valve Body 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? • Valve 2
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 702-16-51140 • Shim, T=0.30mm 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54670 • Shim, T=0.20mm 4
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54550 • Spring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54571 • Retainer 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54560 • Spring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-53170 • Piston 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-51270 • Seal 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54580 • Collar 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54590 • O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • Lever 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? • Plate 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? • Shaft 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 702-16-54641 • Boot 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 01252-30625 • Bolt 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54660 • Plate 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-54650 • Plate 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-21-07610 • Valve, Solenoid 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-21-53680 • • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-21-55620 • • Plug 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-21-53330 • • Screw 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 • • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 700-22-11410 • O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-21-39450 • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07000-11008 • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07000-12012 • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • Body 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 01252-60612 • Bolt 3
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 203-60-62220 • Bolt 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
