Содержание Excavators Komatsu PC360LC-10 S/N K60001-UP(PC360L2U)
Solenoid Valve Piping, with Additional Actuator Piping, Accumulator, for EU Arrangement, Solenoid Valve Related Parts(H027002 : H1831-003002)
Номер на схеме Каталожный номер Название Количество Детали
? 01010-81090 Bolt 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 01643-31032 Washer 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 22U-60-21330 Accumulator 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-12034 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 207-62-61680 Tee 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02783-10210 Elbow 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 20Y-62-16630 Nipple 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 201-60-11390 • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 20Y-62-19560 • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02781-0021D Union 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 208-62-71750 Elbow 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 21W-62-42490 Elbow 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11009 O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 11Y-62-12130 Nipple 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 20Y-62-41960 Tee 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 11Y-62-12330 Tee 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11008 O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02781-00422 Union 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11012 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-12034 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 20Y-62-21940 Filter Assembly 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-12034 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 21N-64-36680 Tee 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02896-11009 O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07002-11423 O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 08034-20536 Band 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 02789-10315 Plug 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? (207-62-41931) Hose
KIT-FLAG: _-
SCC:
SERIALNO: -
 H1810-002001

Excavators Komatsu / PC360LC-10 S/N K60001-UP(PC360L2U) / Solenoid Valve Piping, with Additional Actuator Piping, Accumulator, for EU Arrangement, Solenoid Valve Related Parts(H027002 : H1831-003002)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
