Содержание Excavators Komatsu PC360LC-10 S/N K60001-UP(PC360L2U)
Main Control Valve, with 1-additional Actuator Piping, Accumulator, Anti-drop Valve, Boom and Arm, Inner Parts (3/23)(H004003 : H0120-003003)
Номер на схеме Каталожный номер Название Количество Детали
? 723-48-26900 Valve Assembly, Control 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • Body Subassembly 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 723-46-18330 • • Case Subassembly 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • • • Case 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 723-46-17340 • • • Plug 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07000-13024 • • • O-Ring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • • • Screw 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 723-46-17320 • • • Spool 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-17330 • • • Spring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-18431 • • Case Subassembly 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • • • Case 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? • • • Piston 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? • • • Seal 1
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 723-46-17320 • • • Spool 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-17330 • • • Spring 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-15630 • • • Plug 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-17340 • • • Plug 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 07000-13024 • • • O-Ring 2
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? • • • Screw 3
SN: K60001-
KIT-FLAG: _-
SCC: C1
SERIALNO: K60001-
? 07430-71380 • • O-Ring 12
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 702-16-53920 • • O-Ring 8
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 01252-60820 • • Bolt 23
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
? 723-46-17350 • • Bolt 1
SN: K60001-
KIT-FLAG: _-
SCC:
SERIALNO: K60001-
