| Наименование | Страница | Код страницы |
|---|---|---|
| BURST VALVE LINE (BOOM AND ARM CHASSIS SIDE) | 006026 | H1250-02A1 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-62-73570 | BLOCK | 1 | SN: K50001- |
|||
| ? | 20Y-62-45280 | PLATE | 1 | SN: K50001- |
|||
| ? | 01011-81210 | BOLT | 2 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 2 | SN: K50001- |
|||
| ? | 02781-00522 | UNION | 2 | SN: K50001- |
|||
| ? | 07002-12434 | O-RING | 2 | SN: K50001- |
|||
| ? | 02896-11015 | O-RING | 2 | SN: K50001- |
|||
| ? | 02781-00315 | UNION | 2 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 2 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 02762-00512 | HOSE | 1 | SN: K50001- |
|||
| ? | 08034-20536 | BAND | 3 | SN: K50001- |
|||
| ? | 02762-00565 | HOSE | 1 | SN: K50001- |
|||
| ? | 02762-00364 | HOSE | 1 | SN: K50001- |
|||
| ? | 207-62-54760 | CLAMP | 3 | SN: K50001- |
|||
| ? | 207-62-55160 | CLAMP | 3 | SN: K50001- |
|||
| ? | 01010-81230 | BOLT | 3 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 3 | SN: K50001- |
|||
| ? | 142-03-11160 | SPACER | 3 | SN: K50001- |
|||
| ? | 04434-53212 | CLIP | 3 | SN: K50001- |
|||
| ? | 07095-20523 | CUSHION | 3 | SN: K50001- |
|||
| ? | 04434-51912 | CLIP | 3 | SN: K50001- |
|||
| ? | 07095-20213 | CUSHION | 3 | SN: K50001- |
|||
| ? | 01010-81280 | BOLT | 3 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 3 | SN: K50001- |
|||
| ? | 175-40-22540 | SPACER | 2 | SN: K50001- |
|||
| ? | 04434-53212 | CLIP | 2 | SN: K50001- |
|||
| ? | 07095-20523 | CUSHION | 2 | SN: K50001- |
|||
| ? | 04434-51912 | CLIP | 2 | SN: K50001- |
|||
| ? | 07095-20213 | CUSHION | 2 | SN: K50001- |
|||
| ? | 01010-81290 | BOLT | 2 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 2 | SN: K50001- |
|||
| ? | 142-03-11160 | SPACER | 1 | SN: K50001- |
|||
| ? | 207-977-5120 | BRACKET | 1 | SN: K50001- |
|||
| ? | 01010-81275 | BOLT | 1 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: K50001- |
|||
| ? | 04434-53212 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20523 | CUSHION | 1 | SN: K50001- |
|||
| ? | 04434-51912 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20213 | CUSHION | 1 | SN: K50001- |
|||
| ? | 01010-81225 | BOLT | 1 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: K50001- |
|||
| ? | 142-03-11160 | SPACER | 1 | SN: K50001- |
|||
| ? | 04434-53212 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20523 | CUSHION | 1 | SN: K50001- |
|||
| ? | 04434-51912 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20213 | CUSHION | 1 | SN: K50001- |
|||
| ? | 01010-81275 | BOLT | 1 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: K50001- |
|||
| ? | 04434-53212 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20523 | CUSHION | 1 | SN: K50001- |
|||
| ? | 04434-51912 | CLIP | 1 | SN: K50001- |
|||
| ? | 07095-20213 | CUSHION | 1 | SN: K50001- |
|||
| ? | 421-09-31120 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-12434 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11015 | O-RING | 1 | SN: K50001- |
|||
| ? | 02782-10311 | ELBOW | 1 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 1 | SN: K50001- |
|||
| ? | (207-62-63230) | BLOCK | 1 | SN: K50001- |
H1250-02A1 |
