| Наименование | Страница | Код страницы |
|---|---|---|
| BURST VALVE (FOR ARM CYLINDER) | 017144 | Y1679-11A1 |
| BURST VALVE (FOR ARM CYLINDER) | 017144 | Y1679-11A1 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (702-21-08731) | PILOT VALVE | 1 | SN: K50595- |
Y1679-11A1 | ||
| ? | (702-21-08730) | PILOT VALVE | 1 | SN: K50001-K50594 |
Y1679-11A1 | ||
| ? | 07000-13035 | O-RING | 1 | SN: K50001- |
|||
| ? | 01435-01055 | BOLT | 2 | SN: K50001- |
|||
| ? | 01435-01065 | BOLT | 2 | SN: K50001- |
|||
| ? | 208-62-72880 | TUBE | 1 | SN: K50001- |
|||
| ? | 07000-13035 | O-RING | 1 | SN: K50001- |
|||
| ? | 07372-21040 | BOLT | 4 | SN: K50001- |
|||
| ? | 01643-51032 | WASHER | 4 | SN: K50001- |
|||
| ? | 07040-11409 | PLUG | 1 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 707-88-25450 | BRACKET | 1 | SN: K50001- |
|||
| ? | 707-88-21880 | BAND | 1 | SN: K50001- |
|||
| ? | 01435-01235 | BOLT | 2 | SN: K50001- |
|||
| ? | 07283-33450 | CLIP | 1 | SN: K50001- |
|||
| ? | 01597-01009 | NUT | 2 | SN: K50001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: K50001- |
|||
| ? | 07283-33450 | CLIP | 1 | SN: K50001- |
|||
| ? | 01597-01009 | NUT | 2 | SN: K50001- |
|||
| ? | 01643-31032 | WASHER | 2 | SN: K50001- |
