| Наименование | Страница | Код страницы |
|---|---|---|
| AIR CLEANER (INNER PARTS) | 017002 | Y1011-01A0 |
| AIR CLEANER (INNER PARTS) | 017002 | Y1011-01A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6156-81-7202) | AIR CLEANER ASSEMBLY | 1 | SN: K50636- |
Y1011-01A0 | ||
| ? | (6156-81-7201) | AIR CLEANER ASSEMBLY | 1 | SN: K50001-K50635 |
Y1011-01A0 | ||
| ? | 6151-11-9970 | BAND ASSEMBLY | 2 | SN: K50001- |
|||
| ? | 6643-11-4641 | BOLT | 2 | SN: K50001- |
|||
| ? | 208-01-72220 | BRACKET | 1 | SN: K50001- |
|||
| ? | 01010-81225 | BOLT | 4 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: K50001- |
|||
| ? | 11Y-01-11920 | JOINT | 1 | SN: K50001- |
|||
| ? | 208-01-72310 | SEAL | 1 | SN: K50001- |
|||
| ? | 208-01-72111 | HOSE | 1 | SN: K50001- |
|||
| ? | 208-01-72180 | CLAMP | 1 | SN: K50001- |
|||
| ? | 07299-00130 | CLAMP | 1 | SN: K50001- |
|||
| ? | 208-01-72151 | TUBE | 1 | SN: K50001- |
|||
| ? | 07283-31185 | CLIP | 1 | SN: K50001- |
|||
| ? | 01597-01211 | NUT | 2 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 2 | SN: K50001- |
|||
| ? | 208-01-72161 | HOSE | 1 | SN: K50001- |
|||
| ? | 07299-00130 | CLAMP | 2 | SN: K50001- |
|||
| ? | 20Y-06-42910 | SENSOR | 1 | SN: K50572- |
|||
| ? | 7861-93-1421 | SENSOR | 1 | SN: K50523-K50571 |
|||
| ? | 7861-93-1420 | SENSOR | 1 | SN: K50001-K50522 |
|||
| ? | 208-01-75310 | COVER | 1 | SN: K50001-K50088 |
|||
| ? | 208-01-75320 | COVER | 2 | SN: K50001-K50088 |
