| Наименование | Страница | Код страницы |
|---|---|---|
| BOOM (6.7M) (ARM CYLINDER LINE) | 013007 | T1110-04A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-62-74130 | TUBE | 1 | SN: K50001- |
|||
| ? | 208-62-74750 | TUBE | 1 | SN: K50001- |
|||
| ? | 07000-13035 | O-RING | 1 | SN: K50001- |
|||
| ? | 07372-21040 | BOLT | 4 | SN: K50001- |
|||
| ? | 01643-51032 | WASHER | 4 | SN: K50001- |
|||
| ? | 207-62-31330 | CLAMP | 2 | SN: K50001- |
|||
| ? | 207-62-52350 | CLAMP | 2 | SN: K50001- |
|||
| ? | 205-62-73431 | SEAT | 2 | SN: K50001- |
|||
| ? | 01010-81235 | BOLT | 6 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 6 | SN: K50001- |
|||
| ? | 208-62-74120 | TUBE | 1 | SN: K50001- |
|||
| ? | 208-62-74740 | TUBE | 1 | SN: K50001- |
|||
| ? | 07000-13035 | O-RING | 1 | SN: K50001- |
|||
| ? | 07372-21040 | BOLT | 4 | SN: K50001- |
|||
| ? | 01643-51032 | WASHER | 4 | SN: K50001- |
|||
| ? | 207-62-31330 | CLAMP | 2 | SN: K50001- |
|||
| ? | 207-62-52350 | CLAMP | 2 | SN: K50001- |
|||
| ? | 205-62-73431 | SEAT | 2 | SN: K50001- |
|||
| ? | 01010-81235 | BOLT | 6 | SN: K50001- |
|||
| ? | 01643-31232 | WASHER | 6 | SN: K50001- |
|||
| ? | (208-62-74760) | TUBE | 1 | SN: K50001- |
T1110-04A0 |
