| Наименование | Страница | Код страницы |
|---|---|---|
| SOLENOID VALVE (INNER PARTS) | 017147 | Y1860-01A1 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (207-60-71320) | VALVE ASSEMBLY | 1 | SN: K50001- |
Y1860-01A1 | ||
| ? | 20Y-62-22271 | ELBOW | 1 | SN: K50001- |
|||
| ? | 201-60-11390 | • O-RING | 1 | SN: K50001- |
|||
| ? | 20Y-62-19560 | • O-RING | 1 | SN: K50001- |
|||
| ? | 208-62-71750 | ELBOW | 1 | SN: K50001- |
|||
| ? | 02896-11008 | O-RING | 1 | SN: K50001- |
|||
| ? | 02783-10210 | ELBOW | 1 | SN: K50001- |
|||
| ? | 02896-11008 | O-RING | 1 | SN: K50001- |
|||
| ? | 21W-62-42490 | ELBOW | 2 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 11Y-62-12130 | NIPPLE | 1 | SN: K50001- |
|||
| ? | 02896-11008 | O-RING | 1 | SN: K50001- |
|||
| ? | 11Y-62-12330 | ELBOW | 1 | SN: K50001- |
|||
| ? | 02896-11008 | O-RING | 2 | SN: K50001- |
|||
| ? | 21M-62-16350 | ADAPTER | 1 | SN: K50001- |
|||
| ? | 11Y-62-12330 | ELBOW | 1 | SN: K50001- |
|||
| ? | 02896-11008 | O-RING | 2 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 9 | SN: K50001- |
|||
| ? | 02781-00422 | UNION | 1 | SN: K50001- |
|||
| ? | 02896-11012 | O-RING | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 20Y-62-21940 | FILTER ASSEMBLY | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
|||
| ? | 21N-64-36680 | TEE | 1 | SN: K50001- |
|||
| ? | 02896-11009 | O-RING | 2 | SN: K50001- |
|||
| ? | 07002-11423 | O-RING | 1 | SN: K50001- |
|||
| ? | 22U-60-21330 | ACCUMULATOR | 1 | SN: K50001- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: K50001- |
