| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 206-26-71490 | CASE | 1 | SN: K40001-K40219 |
|||
| ? | 20Y-26-22330 | BEARING | 1 | SN: K40001-K40219 |
|||
| ? | 206-26-71240 | BEARING | 1 | SN: K40001-K40219 |
|||
| ? | 206-26-72120 | SHAFT | 1 | SN: K40001-K40219 |
|||
| ? | 07012-00115 | SEAL | 1 | SN: K40001-K40219 |
|||
| ? | 206-26-71310 | SPACER | 1 | SN: K40001-K40219 |
|||
| ? | 07000-15310 | O-RING | 1 | SN: K40001-K40219 |
|||
| ? | 206-26-71480 | CARRIER | 1 | SN: K40001-@ |
|||
| ? | 206-26-71440 | GEAR | 4 | SN: K40001-@ |
|||
| ? | 22U-26-21320 | BEARING | 8 | SN: K40001-@ |
|||
| ? | 206-26-71520 | THRUST WASHER | 8 | SN: K40001-@ |
|||
| ? | 206-26-71510 | PIN | 4 | SN: K40001-@ |
|||
| ? | 20Y-26-21330 | PIN | 4 | SN: K40001-@ |
|||
| ? | 20Y-26-21240 | PLATE | 1 | SN: K40001-@ |
|||
| ? | 112-32-11211 | BOLT ? SHOE | 1 | SN: K40001-@ |
|||
| ? | 206-26-71452 | GEAR | 1 | SN: .-@ |
|||
| ? | 20K-22-11190 | O-RING | 1 | SN: K40001-@ |
|||
| ? | 01010-81440 | BOLT | 22 | SN: K40001-@ |
|||
| ? | 01643-31445 | WASHER | 22 | SN: K40001-@ |
|||
| ? | 206-26-71430 | GEAR | 1 | SN: K40001-@ |
|||
| ? | 04260-01270 | BALL | 1 | SN: K40001-@ |
|||
| ? | 206-26-71470 | CARRIER | 1 | SN: K40001-@ |
|||
| ? | 206-26-71420 | GEAR | 3 | SN: K40001-@ |
|||
| ? | 20Y-27-22210 | BEARING | 3 | SN: K40001-@ |
|||
| ? | 22U-26-21230 | WASHER | 6 | SN: K40001-@ |
|||
| ? | 206-26-71210 | PIN | 3 | SN: K40001-@ |
|||
| ? | 04064-03515 | RING | 6 | SN: K40001-@ |
|||
| ? | 206-26-71350 | HOLDER | 1 | SN: K40001-@ |
|||
| ? | 206-26-71410 | GEAR | 1 | SN: K40001-@ |
|||
| ? | 206-26-71340 | PLATE | 1 | SN: K40001-@ |
|||
| ? | 195-03-13241 | VALVE | 1 | SN: K40001-@ |
|||
| ? | 07270-21560 | TUBE | 1 | SN: K40001-@ |
|||
| ? | 07281-00197 | CLAMP | 1 | SN: K40001-@ |
|||
| ? | 01010-81035 | BOLT | 6 | SN: K40001-@ |
|||
| ? | 01643-51032 | WASHER | 6 | SN: K40001-@ |
|||
| ? | 22U-26-21280 | RING | 1 | SN: K40001-@ |
|||
| ? | 07043-00312 | PLUG | 1 | SN: K40001-@ |
|||
| ? | (706-7G-01040) | MOTOR ASS'Y,(SEE FIG.Y1640-01A0) | 1 | SN: K40001-@ |
|||
| ? | 07000-15250 | O-RING | 1 | SN: K40001-@ |
|||
| ? | 01010-82070 | BOLT | 14 | SN: K40001-@ |
|||
| ? | 01643-32060 | WASHER | 14 | SN: K40001-@ |
|||
| ? | 206-26-71540 | TUBE | 1 | SN: K40001-@ |
|||
| ? | 20Y-26-31420 | FILLER | 1 | SN: K40001-@ |
|||
| ? | 20Y-26-31430 | GAUGE | 1 | SN: K40001-@ |
|||
| ? | 20Y-26-31441 | BRACKET | 1 | SN: K40001-@ |
|||
| ? | 22U-26-21460 | CAP | 1 | SN: K40001-@ |
|||
| ? | 07238-10630 | CONNECTOR | 1 | SN: K40001-@ |
|||
| ? | 07283-32738 | CLIP | 1 | SN: K40001-@ |
|||
| ? | 04434-51710 | CLIP | 1 | SN: K40001-@ |
|||
| ? | 01597-01009 | NUT | 2 | SN: K40001-@ |
|||
| ? | 01643-31032 | WASHER | 2 | SN: K40001-@ |
|||
| ? | 01010-81030 | BOLT | 2 | SN: K40001-. |
|||
| ? | 01643-31032 | WASHER | 2 | SN: K40001-. |
|||
| ? | 01010-81025 | BOLT | 1 | SN: K40001-. |
|||
| ? | 01643-31032 | WASHER | 1 | SN: K40001-. |
|||
| ? | 22U-26-21370 | HOSE | 1 | SN: .-K40219 |
|||
| ? | 22U-26-21380 | PLATE | 1 | SN: .-K40219 |
|||
| ? | 22U-26-21390 | CLAMP | 1 | SN: .-K40219 |
|||
| ? | 205-70-51390 | NIPPLE | 2 | SN: .-K40219 |
|||
| ? | 07020-00000 | FITTING | 1 | SN: .-K40219 |
|||
| ? | 04434-51210 | CLIP | 1 | SN: .-K40219 |
|||
| ? | 130-80-25110 | CLIP | 1 | SN: .-K40219 |
|||
| ? | 01010-81020 | BOLT | 2 | SN: .-K40219 |
|||
| ? | 01643-31032 | WASHER | 2 | SN: .-K40219 |
