| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 707-01-0R081 | CYLINDER GROUP | 1 | SN: K53811- |
|||
| ? | 707-01-0R080 | CYLINDER GROUP | 1 | SN: K50001-K53810 |
|||
| ? | ==================== | ||||||
| ? | 707-01-0H601 | CYLINDER ASSEMBLY | 1 | SN: K53811- |
|||
| ? | 707-01-0H600 | CYLINDER ASSEMBLY | 1 | SN: K50001-K53810 |
|||
| ? | 707-13-13870 | • CYLINDER | 1 | SN: K50001- |
|||
| ? | 707-76-80431 | • BUSHING | 2 | SN: K50001- |
|||
| ? | 07145-00080 | • SEAL, DUST (KIT) | 4 | SN: K53811- |
|||
| ? | 707-77-80010 | • SEAL, DUST (KIT) | 4 | SN: K50001-K53810 |
|||
| ? | 707-58-95270 | • ROD, PISTON | 1 | SN: K50001- |
|||
| ? | 707-27-13850 | • HEAD, CYLINDER | 1 | SN: K50001- |
|||
| ? | 07179-13109 | • RING, SNAP | 1 | SN: K50001- |
|||
| ? | 707-56-95510 | • SEAL, DUST (KIT) | 1 | SN: K53811- |
|||
| ? | 707-56-95730 | • SEAL, DUST (KIT) | 1 | SN: K50001-K53810 |
|||
| ? | 707-52-90721 | • BUSHING | 1 | SN: K53811- |
|||
| ? | 707-52-90720 | • BUSHING | 1 | SN: K50001-K53810 |
|||
| ? | 707-75-95030 | • RING, SNAP | 1 | SN: K50001- |
|||
| ? | 707-51-95030 | • PACKING, ROD (KIT) | 1 | SN: K50001- |
|||
| ? | 07000-15125 | • O-RING (KIT) | 1 | SN: K50001- |
|||
| ? | 707-35-31260 | • RING, BACK-UP (KIT) | 1 | SN: K53811- |
|||
| ? | 707-35-91370 | • RING, BACK-UP (KIT) | 1 | SN: K50001-K53810 |
|||
| ? | 707-51-95650 | • RING, BUFFER (KIT) | 1 | SN: K50001- |
|||
| ? | 01010-81875 | • BOLT | 12 | SN: K50001- |
|||
| ? | 707-41-11840 | • WASHER | 12 | SN: K50001- |
|||
| ? | 707-36-13771 | • PISTON | 1 | SN: K50001- |
|||
| ? | 707-44-13250 | • RING, PISTON (KIT) | 1 | SN: K50001- |
|||
| ? | 707-39-13530 | • RING, WEAR (KIT) | 2 | SN: K50001- |
|||
| ? | 707-44-13920 | • RING | 2 | SN: K50001- |
|||
| ? | 707-71-71010 | • PLUNGER | 1 | SN: K53811- |
|||
| ? | 707-71-71070 | • PLUNGER | 1 | SN: K50001-K53810 |
|||
| ? | 07000-15085 | • O-RING (KIT) | 1 | SN: K50001- |
|||
| ? | 707-35-30850 | • RING, BACK-UP (KIT) | 2 | SN: K53811- |
|||
| ? | 707-35-90960 | • RING, BACK-UP (KIT) | 2 | SN: K50001-K53810 |
|||
| ? | 01310-01216 | • SCREW | 1 | SN: K50001- |
|||
| ? | 707-71-80270 | • PLUNGER | 1 | SN: K50001- |
|||
| ? | 07020-00000 | • FITTING, GREASE | 1 | SN: K50001- |
|||
| ? | 707-71-34980 | • COLLAR | 1 | SN: K50001- |
|||
| ? | 707-35-31260 | • RING, BACK-UP (KIT) | 2 | SN: K53811- |
|||
| ? | 707-35-91370 | • RING, BACK-UP (KIT) | 2 | SN: K50001-K53810 |
|||
| ? | 07000-15125 | • O-RING (KIT) | 1 | SN: K50001- |
|||
| ? | 04260-00635 | • BALL | 12 | SN: K50001- |
|||
| ? | 707-71-91270 | • CAP | 1 | SN: K50001- |
|||
| ? | 707-83-13010 | • VALVE | 1 | SN: K50001- |
|||
| ? | 07750-01628 | • SPRING | 1 | SN: K50001- |
|||
| ? | 707-87-14070 | • PLUG | 1 | SN: K50001- |
|||
| ? | 07002-12034 | • O-RING (KIT) | 1 | SN: K50001- |
|||
| ? | 20Y-62-K7110 | TUBE | 1 | SN: K50001- |
|||
| ? | 07372-51060 | BOLT | 2 | SN: K50001- |
|||
| ? | 01643-51032 | WASHER | 2 | SN: K50001- |
|||
| ? | 07372-51045 | BOLT | 2 | SN: K50001- |
|||
| ? | 01643-51032 | WASHER | 2 | SN: K50001- |
|||
| ? | 07000-13030 | O-RING (KIT) | 1 | SN: K50001- |
|||
| ? | ==================== | ||||||
| ? | 707-99-50500 | SERVICE KIT | 1 | SN: K53811- |
|||
| ? | 707-98-48610 | SERVICE KIT | 1 | SN: K50001-K53810 |
