| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-2L-00701) | PUMP ASSEMBLY | 1 | SN: K54697- |
|||
| ? | (708-2L-00700) | PUMP ASSEMBLY | 1 | SN: K50001-K54696 |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-11A0. | ||||||
| ? | (708-2L-01701) | • PUMP SUB ASSEMBLY | 1 | SN: K54697- |
|||
| ? | (708-2L-01700) | • PUMP SUB ASSEMBLY | 1 | SN: K50001-K54696 |
|||
| ? | (★708-2L-42210) | • • SHAFT, FRONT | 1 | SN: K50001- |
|||
| ? | (★708-2L-42250) | • • BEARING | 1 | SN: K50001- |
|||
| ? | (★708-2E-05040) | • • WASHER KIT | 1 | SN: K50001- |
|||
| ? | ☆ | • • • WASHER, 3.1MM | 1 | SN: K50001- |
|||
| ? | ☆ | • • • WASHER, 3.0MM | 1 | SN: K50001- |
|||
| ? | ☆ | • • • WASHER, 2.9MM | 1 | SN: K50001- |
|||
| ? | ☆ | • • • WASHER, 2.8MM | 1 | SN: K50001- |
|||
| ? | (★708-25-12790) | • • RING, SNAP | 1 | SN: K50001- |
|||
| ? | 708-25-52861 | • • SEAL, OIL | 1 | SN: K50001- |
|||
| ? | 708-2L-22160 | • • SPACER | 1 | SN: K50001- |
|||
| ? | 04065-06825 | • • RING, SNAP | 1 | SN: K50001- |
|||
| ? | (★708-2L-06590) | • • BLOCK ASSEMBLY, FRONT | 1 | SN: K50001- |
|||
| ? | ☆ | • • • BLOCK, CYLINDER | 1 | SN: K50001- |
|||
| ? | ☆ | • • • PLATE, VALVE | 1 | SN: K50001- |
|||
| ? | (★708-18-13230) | • • PIN | 1 | SN: K50001- |
|||
| ? | (★04065-05820) | • • RING, SNAP | 1 | SN: K50001- |
|||
| ? | (★708-2L-43130) | • • SEAT | 1 | SN: K50001- |
|||
| ? | (★708-2L-43150) | • • SPRING | 1 | SN: K50001- |
|||
| ? | (★708-2H-23141) | • • SEAT | 1 | SN: K50001- |
|||
| ? | (★708-2L-43510) | • • GUIDE, RETAINER | 1 | SN: K50001- |
|||
| ? | (★708-2L-43360) | • • PIN | 3 | SN: K50001- |
|||
| ? | (★708-2L-43340) | • • RETAINER, SHOE | 1 | SN: K50001- |
|||
| ? | (★708-2L-43311) | • • PISTON SUB ASSEMBLY | 9 | SN: K50001- |
|||
| ? | (★708-2L-06262) | • • CRADLE ASSEMBLY | 1 | SN: K50001- |
|||
| ? | ☆ | • • • CRADLE | 1 | SN: K50001- |
|||
| ? | ☆ | • • • CAM, ROCKER | 1 | SN: K50001- |
|||
| ? | (★04020-01228) | • • PIN, DOWEL | 1 | SN: K50001- |
|||
| ? | (★01252-61025) | • • BOLT | 6 | SN: K50001- |
