| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-62-K7540 | FITTING | 5 | SN: K52390- |
|||
| ? | 20Y-62-K7530 | FITTING | 5 | SN: K52390- |
|||
| ? | 20Y-70-K4580 | BLOCK ASSEMBLY | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7480 | • BLOCK | 1 | SN: K52390- |
|||
| ? | 20Y-62-K8140 | • HOSE | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7870 | BRACKET | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7360 | TUBE | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7370 | TUBE | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7520 | UNION | 4 | SN: K52390- |
|||
| ? | 20Y-62-K7380 | TUBE | 1 | SN: K52390- |
|||
| ? | 20Y-62-K7390 | TUBE | 1 | SN: K52390- |
|||
| ? | 20Y-62-K9432 | BRACKET | 5 | SN: K54608- |
|||
| ? | □20Y-62-K9431 | BRACKET | 5 | SN: K52513-K54607 |
|||
| ? | 20Y-62-K9430 | BRACKET | 5 | SN: K52390-K52512 |
|||
| ? | 07283-32746 | CLIP | 5 | SN: K52390- |
|||
| ? | 01643-31032 | WASHER | 12 | SN: K52390- |
|||
| ? | 01597-01009 | NUT | 12 | SN: K52390- |
|||
| ? | 20Y-62-K8582 | CLAMP | 6 | SN: K54608- |
|||
| ? | □20Y-62-K8581 | CLAMP | 6 | SN: K52513-K54607 |
|||
| ? | 20Y-62-K8580 | CLAMP | 6 | SN: K52390-K52512 |
|||
| ? | 07283-52737 | SEAT | 5 | SN: K52390- |
|||
| ? | 07283-53444 | SEAT | 1 | SN: K52390- |
|||
| ? | 01010-81025 | BOLT | 6 | SN: K52390- |
|||
| ? | 01643-31032 | WASHER | 6 | SN: K52390- |
|||
| ? | 04435-51212 | CLIP | 3 | SN: K52390- |
|||
| ? | 04434-50812 | CLIP | 3 | SN: K52513- |
|||
| ? | 04435-51212 | CLIP | 3 | SN: K52390-K52512 |
|||
| ? | 04434-51812 | CLIP | 1 | SN: K52451- |
|||
| ? | 04435-51912 | CLIP | 1 | SN: K52390-K52450 |
|||
| ? | 04435-52112 | CLIP | 1 | SN: K52451- |
|||
| ? | 04434-51212 | CLIP | 1 | SN: K52390-K52450 |
|||
| ? | 20Y-62-K7312 | BRACKET | 1 | SN: K54608- |
|||
| ? | □20Y-62-K7311 | BRACKET | 1 | SN: K52513-K54607 |
|||
| ? | 20Y-62-K7310 | BRACKET | 1 | SN: K52390-K52512 |
|||
| ? | 07283-33450 | CLIP | 1 | SN: K52390- |
|||
| ? | 20Y-06-K1031 | HARNESS | 1 | SN: K52451- |
|||
| ? | 20Y-06-K1030 | HARNESS | 1 | SN: K52390-K52450 |
|||
| ? | 20Y-06-K2770 | SPACER | 1 | SN: K52451- |
|||
| ? | 01010-81280 | BOLT | 1 | SN: K52451- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: K52390- |
|||
| ? | 195-33-11220 | SPACER | 1 | SN: K52451- |
|||
| ? | 01010-81260 | BOLT | 1 | SN: K52451- |
|||
| ? | 01643-31232 | WASHER | 1 | SN: K52390- |
|||
| ? | 01010-81240 | BOLT | 2 | SN: K52513- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: K52513- |
|||
| ? | 01010-81025 | BOLT | 1 | SN: K52390-K52512 |
|||
| ? | 01643-31032 | WASHER | 1 | SN: K52390- |
