| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (723-47-20402) | VALVE ASSEMBLY | 1 | SN: K40360-K41134 |
|||
| ? | (723-47-20401) | VALVE ASSEMBLY | 1 | SN: K40001-K40359 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-19A0. | ||||||
| ? | 723-40-71103 | • VALVE ASSEMBLY | 1 | SN: K40360-K41134 |
|||
| ? | 723-40-71102 | • VALVE ASSEMBLY | 1 | SN: K40001-K40359 |
|||
| ? | ☆ | • • BODY | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: K40001-K41134 |
|||
| ? | 723-40-71330 | • • RETAINER | 1 | SN: K40001-K41134 |
|||
| ? | 723-40-71340 | • • SPRING | 1 | SN: K40001-K41134 |
|||
| ? | 01252-60816 | • • BOLT | 1 | SN: K40001-K41134 |
|||
| ? | 723-46-15111 | • • CASE | 1 | SN: K40001-K41134 |
|||
| ? | 723-40-71350 | • • RETAINER | 1 | SN: K40001-K41134 |
|||
| ? | 07430-71380 | • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | 01252-60820 | • • BOLT | 2 | SN: K40001-K41134 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: K40360-K41134 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: K40001-K40359 |
|||
| ? | 723-40-71440 | • • SPRING | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • PLUG | 1 | SN: K40001-K41134 |
|||
| ? | 709-74-91860 | • • PLUG | 1 | SN: K40001-K41134 |
|||
| ? | 07002-12434 | • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • SPOOL | 1 | SN: K40001-K41134 |
|||
| ? | 723-40-71390 | • • SPRING | 1 | SN: K40001-K41134 |
|||
| ? | 723-40-61150 | • • PLUG | 1 | SN: K40001-K41134 |
|||
| ? | 07002-12434 | • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • VALVE ASSEMBLY, RELIEF | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • SLEEVE | 1 | SN: K40001-K41134 |
|||
| ? | 702-21-55750 | • • • COLLAR | 1 | SN: K40001-K41134 |
|||
| ? | 702-21-55760 | • • • FILTER | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • POPPET | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • SPRING | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • SCREW | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • NUT | 1 | SN: K40001-K41134 |
|||
| ? | 723-11-19660 | • • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | 702-16-53920 | • • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • O-RING | 1 | SN: K40001-K41134 |
|||
| ? | 07002-11623 | • • • O-RING | 1 | SN: K40001-K41134 |
