| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (708-2L-00202) | PUMP ASSEMBLY | 1 | SN: K41135- |
|||
| ? | (708-2L-00200) | PUMP ASSEMBLY | 1 | SN: K40001-K41134 |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 TO Y1600-11A0. | ||||||
| ? | (708-2L-01203) | • PUMP SUB ASSEMBLY | 1 | SN: K41135- |
|||
| ? | (708-2L-01201) | • PUMP SUB ASSEMBLY | 1 | SN: K40001-K41134 |
|||
| ? | (★708-2L-06293) | • • CAP ASSEMBLY, END | 1 | SN: K41135- |
|||
| ? | (★708-2L-06292) | • • CAP ASSEMBLY, END | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • CAP, END | 1 | SN: K41135- |
|||
| ? | ☆ | • • • CAP, END | 1 | SN: K40001-K41134 |
|||
| ? | ☆ | • • • PLUG | 46 | SN: K40001- |
|||
| ? | (★708-1L-29340) | • • ORIFICE | 2 | SN: K40001- |
|||
| ? | (★708-2L-42150) | • • BEARING | 2 | SN: K40001- |
|||
| ? | (★07000-A5190) | • • O-RING | 2 | SN: K40001- |
|||
| ? | (★04020-01228) | • • PIN | 2 | SN: K40001- |
|||
| ? | (★07040-12414) | • • PLUG | 1 | SN: K40001- |
|||
| ? | (★07002-62434) | • • O-RING | 1 | SN: K40001- |
|||
| ? | (★708-2L-25480) | • • FILTER | 4 | SN: K40001- |
|||
| ? | (★01010-61655) | • • BOLT | 12 | SN: K40001- |
|||
| ? | (★01643-31645) | • • WASHER | 12 | SN: K40001- |
|||
| ? | 708-8E-16150 | • • PLUG | 4 | SN: K40001- |
|||
| ? | 07002-61023 | • • O-RING | 4 | SN: K40001- |
