| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (20Y-54-K1400) | OPERATOR'S CAB ASS'Y | 1 | SN: K20175- |
|||
| ? | (20Y-54-K1400) | OPERATOR'S CAB ASS'Y | 1 | SN: .-K20174 |
|||
| ? | (20Y-54-K1100) | OPERATOR'S CAB ASS'Y | 1 | SN: K20001-. |
|||
| ? | THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.5201 TO 5206. | ||||||
| ? | 20Y-54-K1620 | • WINDOW ASS'Y,UPPER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1630 | • • FRAME,WINDOW | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1640 | • • GLASS | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1650 | • • SEAL,GLAZING | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1660 | • • SEAL,GLAZING | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1670 | • • WIPER MOTOR ASS'Y | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1680 | • • COVER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1690 | • • ARM,WIPER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1730 | • • BLADE,WIPER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1740 | • • WIRING HARNESS | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1720 | • • BRACKET | 1 | SN: K20001- |
|||
| ? | 01010-50612 | • • BOLT | 1 | SN: K20001- |
|||
| ? | 01641-20608 | • • WASHER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1710 | • • TRIM | 2 | SN: K20001- |
|||
| ? | 20Y-54-K3330 | • • CLIP | 1 | SN: K20001- |
|||
| ? | 01010-50616 | • • BOLT | 1 | SN: K20001- |
|||
| ? | 01641-20608 | • • WASHER | 2 | SN: K20001- |
|||
| ? | 01598-00608 | • • NUT,LOCK | 1 | SN: K20001- |
|||
| ? | 20Y-54-K1770 | • • SEAL | 1 | SN: K20001- |
|||
| ? | 01224-40508 | • • SCREW | 4 | SN: K20001- |
|||
| ? | 20Y-54-K2681 | • • SHOOT BOLT ASS'Y,L.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2691 | • • SHOOT BOLT ASS'Y,R.H. | 1 | SN: K20001- |
|||
| ? | 01010-50820 | • • BOLT | 4 | SN: K20001- |
|||
| ? | 20Y-54-K3320 | • • WASHER | 4 | SN: K20001- |
|||
| ? | 20Y-54-K1780 | • • BUFFER | 1 | SN: K20001- |
|||
| ? | 01580-10605 | • • NUT | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2330 | • ROLLER,UPPER | 2 | SN: K20001- |
|||
| ? | 20Y-54-K2340 | • ROLLER,LOWER | 2 | SN: K20001- |
|||
| ? | 20Y-54-K1980 | • SUPPORT | 2 | SN: K20001- |
|||
| ? | 20Y-54-K1990 | • BLOCK | 2 | SN: K20001- |
|||
| ? | 20Y-54-K2130 | • SHIM | 2 | SN: K20001- |
|||
| ? | 20Y-54-K2120 | • SHIM ? 1.0MM | 2 | SN: K20001- |
|||
| ? | 20Y-54-K2110 | • SHIM ? 1.5MM | 2 | SN: K20001- |
|||
| ? | 01010-50816 | • BOLT | 4 | SN: K20001- |
|||
| ? | 01641-20812 | • WASHER | 4 | SN: K20001- |
|||
| ? | 20Y-54-K2140 | • WINDOW ASS'Y,LOWER | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2640 | • • GLASS | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2650 | • • SEAL | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2660 | • • LOCK MOUNT,L.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2670 | • • LOCK MOUNT,R.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2680 | • • BOLT,SHOOT ? L.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2690 | • • BOLT,SHOOT ? R.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2720 | • • SPRING | 2 | SN: K20001- |
|||
| ? | 04025-00416 | • • PIN,SPRING | 4 | SN: K20001- |
|||
| ? | 20Y-54-K2710 | • • PLATE | 2 | SN: K20001- |
|||
| ? | 01235-40616 | • • SCREW | 4 | SN: K20001- |
|||
| ? | 20Y-54-K2420 | • SEAL | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2320 | • DOVE TAIL,L.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2310 | • DOVE TAIL,R.H. | 1 | SN: K20001- |
|||
| ? | 01010-51022 | • BOLT | 4 | SN: K20001- |
|||
| ? | 01641-21016 | • WASHER | 4 | SN: K20001- |
|||
| ? | 20Y-54-K2280 | • BUFFER | 2 | SN: K20001- |
|||
| ? | 01580-10605 | • NUT | 2 | SN: K20001- |
|||
| ? | 20Y-54-K2270 | • BLOCK | 2 | SN: K20001- |
|||
| ? | 01010-50620 | • BOLT | 4 | SN: K20001- |
|||
| ? | 20Y-54-K3330 | • CLIP | 1 | SN: .- |
|||
| ? | 20Y-54-K2470 | • CLIP | 1 | SN: K20001-. |
|||
| ? | 20Y-54-K3130 | • SCREW | 1 | SN: .- |
|||
| ? | 20Y-54-K2480 | • SCREW | 1 | SN: K20001-. |
|||
| ? | 01641-20508 | • WASHER | 1 | SN: .- |
|||
| ? | 20Y-54-K2220 | • SUPPORT,L.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2230 | • SUPPORT,R.H. | 1 | SN: K20001- |
|||
| ? | 20Y-54-K2730 | • SCREW | 4 | SN: K20001- |
|||
| ? | 08056-00630 | • HOLDER | 1 | SN: K20001- |
|||
| ? | 08056-00621 | • HOLDER | 1 | SN: K20001- |
